Miller Electric AY7 - Manual

Processes
TIG (GTAW)
MIG (GMAW)
Plasma Cutting
Resistance Welding
Input Power Single-Phase
Input Voltage 115 VAC or 230 VAC, 50/60 Hz
Max. Cooling Capacity 12,000 – 15,000 BTU/hr at
1.3 qt/min (1.25 L/min)
Weight 44 – 115 lb (20 – 52 kg)
Heavy Industrial Applications
Light/Heavy Manufacturing
Aerospace
Automotive
Tube Mills
Automation
Coolmates and Cool Runners
Coolant
Systems
Issued March 2001 • Index No. AY/7.2
Closed-loop design with radiator reduces
coolant temperatures and prevents the system
from overheating. It also recirculates the
coolant through a fan-cooled heat exchanger.
The Power of Blue ® .
Miller Electric Mfg. Co.
An Illinois Tool Works Company
1635 West Spencer Street
Appleton, WI 54914 USA
Web Site
www.MillerWelds.com
International Headquarters
Phone: 920-735-4505
USA FAX: 920-735-4134
Canadian FAX: 920-735-4169
International FAX: 920-735-4125
Rustproof coolant reservoir molded of poly-
ethylene for durability and corrosion resistance.
Positive vane-style displacement pumps
provide consistent coolant flow and pressure
rating with long pump-life expectancy.
Thermally protected 1/4 HP motor guards
against motor damage due to overheating.
Paddle wheel flow indicator visually confirms
that there is coolant flowing through the system.
Factory-preset pressure-relief valves (55 PSI)
maintain consistent pressure during operation.
Standard inlet/outlet torch fittings are
compatible with TIG and MIG torches having
standard 5/8-18 left-hand fittings.
10 ft (3 m) power cords with plugs are longer
than most power cords in the industry —
providing the extra length when required.
Compatible with Miller coolants and are ideal
for warm and cold weather conditions, while
providing HF or corrosion protection.
Coolmate 3
Coolant systems are warranted for 1 year, parts and labor.
Quick
Specs
Coolmate
™
3, V3, 4, Cool Runner
™
and Cool Runner
™
3X
Coolmate 4
Coolmate V3
