Lights – Mazda 2008 B2300 Truck User Manual

Page 50

5. Carefully pull bulb straight out

of socket and push in the new
bulb.

6. Install the bulb socket in lamp

assembly by turning clockwise.

7. Align the lamp on the vehicle

and push to snap in place.

8. Install the screw on lamp assembly.

Replacing stop lamp/tail lamp/sidemarker lamp/turn lamp/backup
lamp bulbs

These bulbs are located in the same
portion of the tail lamp assembly,
one just below the other. Follow the
same steps to replace either bulb:

1. Open the tailgate to expose the

lamp assemblies.

2. Remove the four screws and the

lamp assembly from vehicle.

3. Rotate the bulb socket

counterclockwise and remove
from lamp assembly.

4. Carefully pull the bulb straight

out of the socket and push in
the new bulb.

5. Install the bulb socket in lamp

assembly by turning clockwise.

6. Install the lamp assembly and

secure with four screws.

2008 B-Series (mbs)
Owners Guide (post-2002-fmt)
USA (fus)

Lights
