ANTENNA CONNECTIONS
External Automotive
Type Antenna Socket
Place the antenna switch in 75 position for
automotive type antennas or 300 for screw
terminal type home stereo antennas.
External Automotive Type Antenna
(Not Provided) (75 ohm)
Di-Pole Type Antenna (300 ohm) (Not Provided)
The units will accept either a standard automotive type antenna plug or the screw terminals of a 300
Ω
ohm di-pole wire antenna
typically used in a home stereo system. Follow the diagram enclosed for the antenna type your are installing
