55
2.65"
28.58"
2.50"
2.70"
Note: add 3.75" to depth for
power supply cable clearance
0.69"
4.25" 6.00
"
9.00"
4.78"
25.24"
28.74"
27.17"
29.17"
1.00"
1.00"
4.78"
0.54"
28.74"
V. 1.5 6/4/95
16x8x2 8-BUS MIXING CONSOLE
©1995 MACKIE DESIGNS INC.
* exclusive
of
meter
bridge
16•8
console
WEIGHT*
50 lbs.
6.00" 5.50"
3.38"
29.20"
MB16•8 Optional Meter Bridge
3.67"
5.50"
