background image

33

MAYTAG ELECTRIC WATER HEATERS
MODEL NUMBERS

HRE2950S

50 GALLON

HRE3950S

50 GALLON

HRE2950T

50 GALLON

HRE3950T

50 GALLON

HRE2966T

66 GALLON

HRE3966T

66 GALLON

Repair Parts List (cont’d)

*Also available at most hardware stores.
†Refer to Wiring Diagram Section for verification.
#Not Illustrated

Now that you have purchased this water heater, should a
need ever exist for repair parts or service, simply call Maytag
Customer Service at 1-800-788-8899 for an authorized ser-
vicer. Be sure to provide all pertinent facts when you call or
visit.

The model number of the water heater will be found on the
model rating plate located above the access panel.

WHEN ORDERING REPAIR PARTS, ALWAYS GIVE
THE FOLLOWING INFORMATION:

Model Number
Serial Number
Part Description
Part Number

THIS IS A REPAIR PARTS LIST, NOT A PACKING LIST.

MODEL NUMBERS

KEY

PART

HRE2950S

HRE3950S

HRE2950T

HRE3950T

HRE2966T

HRE3966T

NO.

DESCRIPTION

PART NUMBERS

1

Temperature-Pressure Relief Valve

66001700

66001700

66001700

66001700

66001700

66001700

2

T&P Insulation

66001709

66001709

3

Dip Tube

66001544

66001544

66001702

66001702

66001702

66001702

4

Drain Valve

66001015

66001015

66001015

66001015

66001015

66001015

5

Drain Valve Washer

66001021

66001021

66001021

66001021

66001021

66001021

17

32

″x

13

64

″x

1

8

″ thick)*

6

Element Gasket

66001053

66001053

66001053

66001053

66001053

66001053

7

Lower Element

SEE NOTE ON PAGE 32

8

Buss Bar Kit

66001055

66001055

66001055

66001055

66001055

66001055

9

Thermostat Bracket

66001054

66001054

66001054

66001054

66001054

66001054

10

2 Pole Thermostat

66001007

66001007

66001007

(Two Wire Lead Models)†

11

Terminal Cover (Lower)

66001268

66001268

66001268

12

Lower Thermostat w/Hi Limit

66001008

66001008

66001008

(Three Wire Lead Models)†

13

Terminal Cover (Lower Three Wire)

66001272

66001272

66001272

14

Lower Access Panel

66001703

66001703

66001703

66001703

66001703

66001703

15

Upper Access Panel

66001703

66001703

66001703

66001703

66001703

66001703

16

Terminal Cover (Upper)

66001064

66001064

66001064

66001064

66001064

66001064

17

Upper Thermostat w/Hi Limit

66001009

66001009

66001009

66001009

66001009

66001009

18

Upper Element

SEE NOTE ON PAGE 32

19

Element Gasket

66001053

66001053

66001053

66001053

66001053

66001053

20

Primary Anode

66001726

66001726

66001727

66001727

66001733

66001733

21

Secondary Anode/Nipple w/Heat Traps

66001217

66001217

66001720

66001720

66001217

66001217

22

Nipple w/Heat Traps

66001707

66001707

66001705

66001705

66001707

66001707

23

Pipe Insulation

66001709

66001709

66001709

66001709

66001709

66001709

#

Manual

66001711
