Meade Instruments 8 x 42 2.0D CaptureView TM Integrated Binocular and Digital Camera User Manual
Page 2
Fig. 1: Top View
1. Diopter Scale (on
underside of right
eyepiece)
2. SD Card Port
3. Eyepiece
4. Menu Button
5. Shutter Button
6. Left Button
7. Right Button
8. LCD Screen
9. Objective Lens
10. Camera Lens
(not visible, see Fig. 2)
11. Barrel
12. USB Port
13. Battery
Compartment Lid
(see Fig. 2)
14. Focus knob (not
visible, see Fig. 2)
b
d
j
i
1!
1@
c
g
h
e
f
Page 2
