7
95-2009 DASH DISASSEMBLY
1
Remove (1) Phillips screw and unsnap right side panel to expose (1) Phillips screw
beneath panel and remove.
Disconnect the negative battery terminal to prevent an accidental short circuit.
3
Unsnap left side panel exposing (1) Phillips screw to remove. 2
Unsnap underside of overhanging dash to unsnap (6) plastic rivets and remove
panel. 4
Remove (5) hex head screws now exposed under overhang. 5
Unsnap bottom edge of trim bezel, then while holding overhang up, unsnap and
remove trim bezel by removing any necessary harnesses. 6
Remove (3) Phillips screw to remove climate control. 7
Remove (2) Phillips screws to remove rear support and (3) 9/32" hex head screws
to remove radio. 8
Continue to kit assembly.
BUICK • RIVIERA 1996-
