11
Specifications
The correlation between published specifications and sonic quality is
unreliable. A list of numbers reveals virtually nothing. All technical
measurements must be subject to qualitative as well as quantitative
interpretation.
Measurements of the Nº28 yield excellent results by any standards.
However, only those specifications that apply to its actual operation
are included here.
■ Power consumption: 50W maximum, depending on options
■ Mains voltage: 100V, 120V, 200V, 220V, or 240VAC @ 50/60Hz
■ Overall dimensions: See "Dimensions"
■ Shipping weight (2 boxes): 29 lbs. (13.2kg)
■ Connector complement: 16 female RCA-type connectors
4 XLR-type female connectors
2 XLR-type male connectors
1 binding post (for turntable ground)
1 ten-pin connector
1 IEC mains connector
■ Gain: Selectable (see "Set-up and installation")
■ Moving-magnet phono option: 38dB, 44dB
■ Moving-coil phono option: 58dB, 64dB
■ Input impedance: Selectable (see "Set-up and installation")
■ Output impedance: 10
Ω
■ Maximum output (TAPE output): 6V
■ Recommended load (TAPE outputs): 10K
Ω
or greater
■ Gain: Selectable (see "Set-up and installation")
■ Single-ended: 6dB, 12dB, 18dB
■ Balanced: 12dB, 18dB, 24dB
■ Input impedance: 15K
Ω
shunted by 220pf
■ Maximum output (MAIN outputs): 6V
■ Recommended load (TAPE outputs): 600
Ω
or greater
For more information, see your Mark Levinson dealer, or contact:
Madrigal Audio Laboratories, Inc.
2081 South Main Street (Route 17), P.O. Box 781
Middletown, Connecticut 06457 USA
Telephone (203) 346-0896
(FAX (203) 346-1540
Phono section
Line section
If purchased in North America, this Mark Levinson product’s warranty is owner-transferable.
Warranty conditions are valid only in the country where the product was originally purchased.
For warranty information and conditions on products purchased outside of North America,
contact your local dealer or regional distributor.
