Mercury 6-5 Stat – Installation & User Guide
Parameter table for 5 Channel Thermostat Continued.......
Number Parameter
Range o C ( o F ) Step Units Default
P-31 Stat4 Temp Cut-In -49 to 30
o
C (-56.2 to 86) 0.1 Deg 15.0
P-32 Stat4 Diff 0 to 10
o
C (32 to 50) 0.1 Deg 5.0
P-33 Stat4 Select 0 = Off
1 = Timer
2 = Probe 1
3 = Probe 2
4 = Probe 3
5 = Probe 4
6 = Probe 5 1 5
P-34 Stat4 Type 0 = Cooling
1 = Heating 1 1
P-36 Stat4 Frost Detect -42 to 128 o C (-43 to 262) 0.1 Deg 0.0
P-37 Stat4 High Temp Alarm -42 to 128
o
C (-43 to 262) 0.1 Deg 25.0
P-38 Stat4 Low Temp Alarm -42 to 128 o C (-43 to 262) 0.1 Deg 0.0
P-39 Stat4 Alm Delay 00:00 to 99:00 01:00 mm:ss 20:00
P-40 Stat4 Rly Inv 0 = Off
1 = On 1 0
P-41 Stat5 Temp Cut-In -49 to 30
o
C (-56.2 to 86) 0.1 Deg 15.0
P-42 Stat5 Diff 0 to 10
o
C (32 to 50) 0.1 Deg 5.0
P-43
Stat5 Select 0 = Off
1 = Timer
2 = Probe 1
3 = Probe 2
4 = Probe 3
5 = Probe 4
6 = Probe 5 1 1
P-44 Stat5 Type 0 = Cooling
1 = Heating 1 1
P-46 Stat5 Frost Detect -42 to 128
o
C (-43 to 262) 0.1 Deg 0.0
P-47 Stat5 High Temp Alarm -42 to 128
o
C (-43 to 262) 0.1 Deg 25.0
P-48 Stat5 Low Temp Alarm -42 to 128
o
C (-43 to 262) 0.1 Deg 0.0
P-49 Stat5 Alm Delay 00:00 to 99:00 01:00 mm:ss 20:00
P-50 Stat5 Rly Inv 0 = Off
1 = On 1 0
P-70 Timer Mode 0 = Local
1 = Remote 1 0
P71 Sunday On Time 1 00:00 to 23:59 00:01 hh:mm 08:00
P72 Sunday Off Time 1 00:00 to 23:59 00:01 hh:mm 20:00
P73 Sunday On Time 2 00:00 to 23:59 00:01 hh:mm 08:00
P74 Sunday Off Time 2 00:00 to 23:59 00:01 hh:mm 20:00
P75 Monday On Time 1 00:00 to 23:59 00:01 hh:mm 08:00
P76 Monday Off Time 1 00:00 to 23:59 00:01 hh:mm 20:00
P77 Monday On Time 2 00:00 to 23:59 00:01 hh:mm 08:00
P78 Monday Off Time 2 00:00 to 23:59 00:01 hh:mm 20:00
Ensure that all power is
switched off before
installing or maintaining
this product
Revision 1.2 Page 8 of 21
