Page 10
9.2 Standard Replacement Parts
Part Number
Item
R125P02-011
MAX-250+ Oxygen Sensor
R125P03-002
MAX-250E Oxygen Sensor
R115P85
MAX-250ESF Oxygen Sensor
R217P08
Gasket
RP06P25
#4-40 Pan Head Stainless Steel Screw
R217P16-001
Front Assembly
(Includes Board & LCD)
R217P11-002
Back Assembly
R217P24
Coiled Cable Assembly
R217P09-001
Overlay
9.3 Optional Accessories
9.3.1 Optional Adapters
Part Number
Item
RP16P02
Blue Tee Adapter
R103P90
Perfusion Tee Adapter
RP16P12
Long-Neck Tee Adapter
RP16P05
Pediatric Tee Adapter
RP16P10
MAX-Quick Connect
R207P17
Threaded Adapter with Tygon Tubing
9.3.2 Mounting Options (requires dovetail)
Part Number
Item
R206P75
Pole Clamp
R205P86
Wall Mount
R213P31
Swivel Mount
R100P10
Rail Mount
R217P23
Dovetail Assembly
9.3.3 Carrying Options
Part Number
Item
RP77P01
Jump Bag
R217P22
Belt Clip and Pin
R213P02
Zipper Carrying Case with Shoulder Strap
R213P56
Deluxe Carrying Case, Water Tight
R217P32
Soft Case, Tight Fit Carrying Case
R213P90
Handi/MAXO
2
®
+
Water Tight Box
13
W W W . M A X T E C I N C . C O M
12
M A N U F A C T U R E D B Y M A X T E C , I N C .
Warm-up Time:
none required
Operating Temperature:
15°C - 40°C (59°F - 104°F)
Storage Temperature:
-15°C - 50°C (5°F - 122°F)
Atmospheric Pressure
800-1013 mBars
Humidity:
0-95% (non-condensing)
Power Requirements:
2, AA Alkaline batteries (2 x 1.5 Volts)
Battery Life:
approximately 5000 hours with continuous use
Low Battery Indication:
"BAT" icon displayed on LCD
Sensor Type:
Maxtec
®
MAX-250+ galvanic fuel cell
Expected Sensor Life:
>900,000 O
2
percent hours minimum 2-years in
typical medical applications
A Model Dimensions:
3.0"(W) x 4.0"(H) x 1.5"(D) [76mm x 102mm x 38mm]
A Weight:
0.4 lbs. (170g)
AE Model Dimensions:
3.0"(W) x 36.0"(H) x 1.5"(D) [76mm x 914mm x 38mm]
Height includes external cable length (retracted).
AE Weight:
0.6 lbs. (285g)
8.2 Sensor Specifications
Type:
Galvanic fuel sensor (0-100%)
Life:
2-years in typical applications
9.0 MAXO
2+
SPARE PARTS AND ACCESSORIES
9.1 Included With Your Unit
Part Number
Item
R217P43-002
MAXO2+A Medical Unit with Sensor
R217P44-002
MAXO2+AE Medical Unit with Sensor
R217M40
User’s Guide and Operating Instructions
R217P27
Quick Reference Calibration Card
RP76P06
Lanyard
R207P17
Threaded Adapter with Tygon Tubing
RP18P01
Screw Driver
R110P10
Flow Diverter
RP16P02
Blue Tee Adapter
R217P10-001
Quick Reference Guide
R217P15-001
Getting Started Guide
R217P10-002
Quick Reference Guide
R217P15-002
Getting Started Guide
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
BAT
CAL
A Model
AE Model
X
X
X
X
X
X
X
X
X
X
X
X
X
X
BAT
CAL
A Model
AE Model
