· Functional Standards:
IEEE 802.3 10BASE-T,
IEEE 803.3u100BASE-TX
IEEE 802.3z 1000BASE-X
IEEE 802.1d Spanning Tree
IEEE 802.1P/Q-GARP/GVAP
IEEE 802.3x Full duplex flow control
IEEE 802.3ad Port trunking
IEEE 802.1P/Q GARP/GVRP
· ISO Certification:
ISO 9001
· Operating
Temperature 0 to 40C (32 to 104 F)
Relative humidity 10% to 90% non-condensing
· Non-operating/storage
Temperature -25 to 70C (-13 to 158 F)
·
Dimensions 440 mm x 245 mm x44.5 mm
(17.32” W x 9.65” D x1.75” H)
·
Weight Net Weight 8.6 lbs (3.9kg)
Gross Weight 10.4 lbs (4.6kg)
·
19” Rack Mount EIA Stamdard
Features/Specifications
· Power for system
· For each port Link/Act, Speed and Duplex/Collision
·
Heat dissipation/hour 42 BTU/hr
·
Maximum wattage: 65W
· Voltage: 110-230 VAC
·
Frequency: 50/60 Hz
Managed Layer 2+ Switch
MIL-S3570EU
24 port 10/100BASE-TX managed switch
MIL-S3570UK 24 port 10/100BASE-TX managed switch
MIL-S3570US 24 port 10/100BASE-TX managed switch
MIL-L3573SX Gigabit uplink port- SC Connector
MIL-L3574SX Gigabit uplink port – MT-RJ connector
Physical Characteristics
Filtering
Power Characteristics
Environmental
Features LED Indicators
Ordering Information
Standards Compliance
Standards
MiLAN T
echnology 1299 Orleans Dr
. Sunnyvale, CA 94089 F: 408.744.2809 PH: 1.800.GO.MiLAN (800.466.4526)
Customer Service and T
echnical Support North America PH: 408.744.2751 [email protected] [email protected]
© 2001 MiLAN Technology. All rights reserved.
MiLAN, MiLAN Technology and the MiLAN Technology logo are either the trademarks or registered
trademarks of Digi International, Inc. in the U.S. and in other countries.
All other brand or product names are trademarks of their respective holders.
o
Ports
· 24 RJ-45 10/100BASE-TX ports
(IEEE 802.3 Type 10BASE-T; 802.3u 100BASE-TX)
· 2 optional 1000BASE-FX ports SC or MT-RJ for Gigabit
uplink module
· Console port RS-232 with a 9-pin D-sub connector
· Software routing with RIP and RIP2
· 12,000 MAC address
· Backpressure flow control for half duplex mode
· Port trunking for up to 800Mbps pipe
· Internal switch database
· Wire speed packet filtering and forwarding
1000BASE SX optional uplinks
· Fiber mode: Mulimode
· Wavelength 850nm
· Connector types SC and MT_RJ
· Fiber Cable 62.5/125mm
· Maximum length 220 m or 500m using 50/125mm cable
Management
· Console RS232 port for local management
· Web-based management
· 802.1D Bridging
· 802.1d Spanning Tree
· 802.1P/Q GARP/GVRP
· SNMP Management
SNMP agent RFC 1155-1157
MIB II
VLAN MIB
Bridge MIB
IGMP MIB
Private MiLAN MIB
RMON MIB (RFC 1757) - static, history alarm, events
· IP Multicast
· GMP Snooping
· IP Multicast filtering
· TFTP software upgrade
· Supports packet filtering and port security
· System wide filtering
· Static MAC destination and source address filtering
· VLAN for multicast/broadcast filtering
· Local port filtering
· Safety
UL 1950;
CSA C22.2 No.950
EN60950
· Emissions
FCC Class A;
EN55022/CISPR 22 Class A
· Immunity
CE Mark-EN61000-X
