Embedded Computers for Automation
>
IA260 Series
Dimensions
Package Checklist
IA260 or IA260-T computer •
Wall mounting kit •
DIN-Rail mounting kit •
Ethernet cable: RJ45 to RJ45 •
cross-over cable, 100 cm
CBL-RJ45F9-150: 8-pin RJ45 to DB9
•
female console port cable, 150 cm
CBL-RJ45M9-150: 8-pin RJ45 to DB9
•
male serial port cable, 150 cm
Universal Power Adaptor
•
Document and Software CD •
Quick Installation Guide (printed) •
Warranty Card •
Ordering Information
Software Specifi cations
112.6 mm
162 mm
52 mm
Linux
Kernel Version: 2.6.23
Protocol Stack: ARP, PPP, CHAP, PAP, IPv4, ICMP, TCP, UDP,
DHCP, FTP, SNMP V1, HTTP, NTP, NFS, SMTP, SSH 1.0/2.0, SSL,
Telnet, PPPoE, OpenVPN
File System: JFFS2, NFS, Ext2, Ext3, VFAT/FAT
System Utilities: bash, tinylogin, telnet, ftp, smtpclient, scp
telnetd: telnet server daemon
sshd: secure shell server
Apache: web server daemon
openvpn: virtual private network
pppd: dial in/out over serial port daeon
snmpd: snmpd agent daeon
inetd: TCP server manager program
openssl: open SSL
Linux Tool Chain:
• GCC (V4.2.1): C/C++ PC Cross Compiler
• GDB (V5.3): Source level debug server
• Glibc (V2.2.5): POSIX standard C library
Windows Embedded CE 6.0
System Utilities: Windows command shell, telnet, ftp,
web-based administration manager
File System: FAT (on-board fl ash)
Protocol Stack: TCP, UDP, IPv4, SNMP V2, ICMP, IGMP, ARP,
HTTP, CHAP, PAP, SSL, DHCP, SNTP, Telnet, FTP, PPP
Telnet Server: Allows remote administration through a standard
telnet client.
FTP Server: Used for transferring fi les to and from remote computer
systems over a network.
Web Server (httpd): Includes ASP, ISAPI Secure Socket Layer
support, SSL 2, SSL 3, Transport Layer Security (TLS/SSL 3.1)
public key-based protocols, and Web Administration ISAPI
Extensions.
Dial-up Networking Service: RAS client API and PPP, supporting
Extensible Authentication Protocol (EAP) and RAS scripting.
Watchdog Server: CPU hardware function for resetting the CPU in a
user-specifi ed time interval; activated by a Moxa library function
Application Development Software:
• Moxa WinCE 6.0 SDK
• C Libraries and Run-times
• Component Services (COM and DCOM)
• Microsoft® .NET Compact Framework 2.0 with SP2
• XML, including DOM, XQL, XPATH, XSLT, SAX
• SOAP Toolkit
• Winsock 2.2
Available Models
IA260-CE: RISC-based embedded computer with 4 serial ports, 8 DIs, 8 DOs, dual LANs, VGA,
CompactFlash, USB, Win CE 6.0 OS, -10 to 60°C operating temperature
IA260-LX: RISC-based industrial embedded computer with 4 serial ports, 8 DIs, 8 DOs, dual LANs,
VGA, CompactFlash, USB, Linux OS, -10 to 60°C operating temperature
IA260-T-CE: RISC-based embedded computer with 4 serial ports, 8 DIs, 8 DOs, dual LANs, VGA,
CompactFlash, USB, Win CE 6.0 OS, -40 to 75°C operating temperature
IA260-T-LX: RISC-based industrial embedded computer with 4 serial ports, 8 DIs, 8 DOs, dual
LANs, VGA, CompactFlash, USB, Linux OS, -40 to 75°C operating temperature
