AMS50
AMPLIFIER SPECIFICATIONS
Issue 1 Page 11 of 12
Output: Power 50 Watts per channel into 8 Ohms (17dBW),
100 Watts per channel into 4 Ohms
Voltage, RMS 20 Volts 20Hz to 20 kHz
Voltage, Peak-to-peak 58 Volts
Current peak-to-peak 100 Amps
Damping factor 190
Output devices 12 per channel
Thermal cut out (internal temp) 70ºC
Balanced Line input:
THD + noise, 20Hz to 20 kHz < 0.006% unwtd.
Signal to noise ratio > 110dB ‘A’-weighted
Input sensitivity for 50 Watts 650mV
Input impedance 50k Ohms
Frequency response 10Hz to 40 kHz, +0, -0.4dB
Connections:
Line level inputs 1 pair line level XLR (balanced) connectors
1 pair line level RCA connectors
Speaker outputs 4 pair 4mm banana plug/binding posts
Trigger input 3.5mm/⅛” mono jack socket
Trigger level ±5V to ±12V
Power requirement:
Mains voltages: 115/230VAC 50/60Hz (factory pre-set)
100VAC 50/60Hz (alternative)
Consumption: 600 Watts maximum into 8 Ohms
14 Watts idle (mains LEDs lit)
Weight:
60 kg 132 lbs unit only, unboxed
65 kg 143 lbs in shipping carton
Dimensions:
483 mm 19 inches wide
325 mm 12¾ inches high including feet
460 mm 18¼ inches deep (front to back) including terminals
Standard accessories:
IEC type mains lead (10-Amp type),
Musical Fidelity reserves the right to make
improvements which may result in specification or
feature changes without notice.
