Set includes
Original image IP Eye Anywhere
without IR LEDs, light sensitivity; 0.5 lux
Conventional Camera
with IR LEDs, light sensitivity; 0.5 lux
Conventional Camera
without IR LEDs, light sensitivity; 2.5 lux
Smart solutions at Home
IP Eye Anywhere TM
Order information
IP Eye Anywhere 10 EU Version Art.nr. 09802
Wired, MJPEG, Black UK Version Art.nr. 09804
IP Eye Anywhere 11 EU Version Art.nr. 09803
Wireless, MJPEG, Black UK Version Art.nr. 09805
IP Eye Anywhere 20 EU Version Art.nr. 09816
Wired, MPEG4, White UK Version Art.nr. 09818
IP Eye Anywhere 21 EU Version Art.nr. 09817
Wireless, MPEG4, White UK Version Art.nr. 09819
Gift box Size (LxWxH) 269x205x89mm
1x IP Camera with built-in
web server
Wireless version with WiFi
antenna
1x Wall/Ceiling bracket
Desktop stand
1x Energy saving switched
mode power supply
1x CD Rom
With UltraView software
package and user manual
(English)
1x RJ45 network cable
1x Quick installation
manual
English, Deutsch, Francais,
Espanol, Italiano, Nederlands.
22736/20080229 © MARMITEK
www.marmitek.com
Technical data
IP Eye Anywhere 10 IP Eye Anywhere 11 IP Eye Anywhere 20 IP Eye Anywhere 21
General
Camera 1/4” colour CMOS, 640 x 480 pixels
Lens F/No 2.6, 4.6 mm F/No 2.8, 4.5 mm
Audio n.a. Internal Microphone
Minimum illumination 0.5 Lux (moonlight view)
View Angle (Diagonal) 60 degrees
Compression MJPEG MPEG4, 5 levels
Frame rate Max 30 fps (frame rate depends on the video format and network performance)
Resolution 160 x 120 pixels, 320 x 240 pixels, 640 x 480 pixels
Power 5VDC 2,5A, 230 V, 6 W max. 5VDC 2,5A, 230 V, 8 W max.
Temperature for use 0°C / +45°C
Communication
LAN port
RJ45, 10/100Mb auto-sense, auto MDI-X
Protocol TCP/IP, UDP, ICMP, DHCP, NTP, DNS, DDNS, SMTP, FTP, HTTP, PPPoE, UPnP
Extra protocols Samba, RTP, RTSP, RTCP
Wireless n.a. 802.11b/g wireless LAN n.a. 802.11b/g wireless LAN
Range dependent on network
Events Triggered by Motion detection (2 scalable windows) or according to schedule
Image Upload/Send over email, FTP
Video Upload/Send n.a. 3GPP, Videofile-to-PC, Network storage, USB Flash disk
Software
Web browser
Configured standard web browser with ActiveX and Java (3 levels, password protected)
Application software UltraView (to view 16 cameras simultaneously)
Minimum system requirements
General
Hardware
CD ROM drive
Operating system MS Windows 2000, XP, Vista
Wired version 10 Base-T Ethernet or 100 Base-TX Fast Ethernet
Wireless version 802.11b/g router/access point (and Ethernet connection for installation)
Camera (viewing by web browser)
Processor Pentium 3, 350 MHz or above Pentium 3, 800 MHz or above
Memory 128 MB RAM, 5 MB free disk space 512 MB RAM, 5 MB free disk space
Web browser Supporting ActiveX and Java
UltraView software
Processor
Pentium 3, 800 MHz or above
Memory 512 MB RAM, 500 / 1000 MB free disk space
