The Series 5000 Premium Eyepieces represent
the highest level of eyepiece technology. Featuring
advanced lens designs with 5, 6 and 7 elements,
super fully multi-coated lenses and some of the
widest fields of view available, they provide the user
with the highest-contrast, pinpoint-sharp images and
spectacular wide field views of the heavens. They
are made to the same high quality standards as the
primary optics in your LS-6 6" telescope and allow you
to get all the performance that the Advanced Coma-
Free and Schmidt-Cassegrain optical systems were
designed to deliver. Use a Series 5000 Telextender for
2, 3 or 5 times the magnification of the eyepiece alone.
There is even a 2x 2 inch Telextender for the large 2
inch eyepieces.
NOTE: 2 inch eyepieces require the optional Series
5000 2” Enhanced Diagonal with 99% Reflectivity
(product number 07677) and the SC Thread to 2"
Accessory Adapter (product number 07085).
Series 5000 Eyepieces
40.0mm 5 EP 2" 60º 38x 1º 34'
32.0mm 5 EP 2" 60º 48x 1º 16'
26.0mm 5 EP 60º 59x 1º 1'
20.0mm 5 EP 60º 76x 47'
14.0mm 5 EP 60º 109x 33'
9.0mm 5 EP 60º 169x 21'
5.5mm 5 EP 60º 277x 13'
Focal Apparent Actual
Length Type Field Power Field
40.0mm SWA 2" 68º 38x 1º 47'
32.0mm SWA 2" 68º 45x 1º 31'
26.0mm SWA 2" 68º 54x 1º 15'
20.0mm SP 68º 64x 4'
15.0mm SP 68º 76x 54'
12.4mm SP 68º 95x 43'
30.0mm UWA 2" 82º 51x 1º 37'
24.0mm UWA 2" 82º 64x 1º 17'
18.0mm UWA 82º 85x 58'
14.0mm UWA 82º 109x 45'
8.8mm UWA 82º 173x 28'
6.7mm UWA 82º 227x 22'
4.7mm UWA 82º 324x 15'
Series 5000 Super Wide Angle
Series 5000 Super Plössl
Series 5000 Ultra Wide Angle
OPTIONAL
ACCESSORIES
1
Series 5000 2” Enhanced Diagonal
