8
Technical Specifications CP In-Wall
Model
Gold CP
In-Wall
Silver CP
In-Wall
Bronze CP
In-Wall
Frequency
response
55Hz – 30KHz 60Hz – 30KHz 62Hz – 22 KHz
Impedance
(nominal)
8 Ohms 8 Ohms 8 Ohms
Sensitivity
(1W@1M)
89dB 89dB 88dB
Maximum SPL 106.5 dBA 105.8 dBA 105 dBA
Power handling 120W 100W 80W
Recommended
Amp
requirements
30-120W 30-100W 20-80W
Bass alignment Sealed enclosure Sealed enclosure Sealed enclosure
Drive unit
complement bass
1x 6.5” C-CAM bass driver
featuring RST technology
1x 6” C-CAM bass driver
1x 6.5” MMP2 second
generation Metal Matrix
Polymer
Drive unit
complement
tweeter
25mm C- CAM gold alloy
dome with high power
ceramic magnet system and
rear low resonance chamber
25mm C- CAM gold alloy
dome with rare earth magnet
25mm C- CAM gold alloy
dome with rare earth
magnet
Overall size
423mm high x 270 wide
(16 11/16 inches x 10 11/16
inches)
423mm high x 270 wide
(16 11/16 inches x 10 11/16
inches)
423mm high x 270 wide
(16 11/16 inches x 10 11/16
inches)
Overall depth 100mm (3 15/16 inches) 100mm (3 15/16 inches) 100mm (3 15/16 inches)
Cut-out hole size
387mm high x 234mm wide
(15 1/4 inches x 9 1/4
inches)
387mm high x 234mm wide
(15 1/4 inches x 9 1/4
inches)
387mm high x 234mm wide
(15 1/4 inches x 9 1/4
inches)
Mounting depth 95mm (3 3/4 inches) 95mm (3 3/4 inches) 95mm (3 3/4 inches)
Controls
+3db / 0dB / -3dB
High frequency attenuation
switch.
+3db / 0dB / -3dB
Mid-range frequency
attenuation switch.
+3db / 0dB / -3dB
High frequency attenuation
switch
Not Applicable
Fixing type 8 position ‘dog’ type fixings 8 position ‘dog’ type fixings 8 position ‘dog’ type fixings
Connection
Gold plated ‘push’ type
terminals
Gold plated ‘push’ type
terminals
Gold plated ‘push’ type
terminals
Baffle material MDF MDF MDF
Back box/
mounting flange
material
Mineral filled ABS plastic (UL
V1 fire rated)
Mineral filled ABS plastic (UL
V1 fire rated)
Mineral filled ABS plastic (UL
V1 fire rated)
Unit weight Kg
(lb)
4.3Kg (9.5Ib) 3.0Kg (6.6Ib) 3.0Kg (6.6lb)
