Issue 4 Page 13 of 14
SPECIFICATIONS
Output
Power 200 Watts per channel into 8 Ohms (23dBW)
Voltage 45 Volts RMS, 20Hz to 20 kHz; onset of clipping
(126 Volts peak-to-peak)
Current peak-to-peak 45 Amps
Damping factor 170
Output devices 2 pairs per channel
Line input
THD+N <0.01% typical, 20Hz to 20 kHz
Signal / noise ratio >100dB ‘A’-weighted
Input impedance 38k Ohms
Frequency response +0, –0.1dB, 10Hz to 20 kHz
Connections
Line level inputs 1 pair line level XLR (balanced) connectors
4 pairs line level RCA connectors
Line level outputs 1 pair line level RCA connectors, constant level TAPE outputs
1 pair line level RCA connectors, preamp outputs for e.g. biamping
USB input USB type “B” (square) socket
Speaker outputs 2 pairs 4mm banana plug/binding posts
Power requirement
Mains voltages 115/230VAC 50/60Hz (factory pre-set)
100VAC 50/60Hz (alternative)
Consumption 680 Watts maximum
Weight
Unit only, unboxed 16.6 kg (36½ lbs)
In shipping carton 21.3 kg (47 lbs)
Dimensions
Wide 440 mm (17⅓”)
High, including feet 125 mm (5”)
Deep (front to back) including terminals 400 mm (15¾”)
Standard accessories
IEC type mains lead (10-Amp type)
M6 remote control
Batteries, LR03 or AAA, manganese alkaline type - 2 off
Musical Fidelity reserves the right to make improvements which may result in
specification or feature changes without notice.
