99-7866 KIT ASSEMBLY

4

A

B

ISO MOUNT RADIO PROVISION WITH POCKET

Mount the ISO Brackets to the radio
using the screws supplied with the
radio. (Figure A)

1

Slide the radio into the radio opening
until it snaps into place. (Figure B)

2

Snap the ISO Trim Plate onto the front
of the Radio Housing. (Figure B)

3

Continue to final assembly.

*

Note: Refer also to the instructions included with the aftermarket radio.
