POWER AV MENU
Features and Controls
6
Installation
33
EJECT Button
Disc loading slot
Caution
Do not bring magnetic devices
such as credit cards or magnetic
cards near the monitor.
....
X
Dome Light Button
POWER Button
AV Select Button
MENU Button
+/- Buttons
PLAY/PAUSE Button
1. Open the package and check that these items are present.
INSTALLATION PLATE UNIT SCREW A SCREW B
2. Connect the external compoments to the RCA cable or AV output.
(Refer to the connection diagram on page 33)
3. Match the position of installation bracket and
installation plate with screw A.
4. Tighten the unit with the supplied
screw B.
SD Input USB Input
AUX Input Jack
R L AUDIO VIDEO AV2 INPUTS
POWER AV MENU
MENU AV POWER
