Users Manual & Installation Guide
PV-
SERIES
: Power supply module with UPS and SSD Flash
Page 3 of 8
F
EATURES AND SPECIFICATIONS
Power Supply
• Output power capability: 30W(max)
• Input voltage: 8-30 VDC or
16-30 VDC using battery charger for 12V battery
• Output voltage: +5V @5A (max)
+12V @250mA(max)
-12V @100mA(max)
• Line regulation(+5V) 0.3% - @low line to high line; full load
• Load regulation(+5V) 0.6% - @no load to full load; nominal input
• Load regulation(+12V) 1% - @no load to full load; nominal input
• Load regulation(-12V) 0.5% - @no load to full load; nominal input
• Ripple/noise: 150mV p-p; DC–20MHz
• LED indicators: Green LED indicating presence of +5V
Green LED indicating presence of +12V
Green LED indicating presence of -12V
Green LED indicating Mains>16V
Battery charger
• Supported battery-type: 12V lead-acid, min. 4AH
• Charging method: Constant current / constant voltage
• Charging current: 400mA
• LED indicators: Yellow LED indicating “Battery full”
• Red LED indicating “Battery low”
UPS
• Alarm outputs: “Mains failure” alarm interrupt
• “Battery low” alarm interrupt
• Interrupt support: INT 5,7,9,10,11,12,15 – programmable
• Automatic shut down: 120 sec after detection of both:
• “Mains failure” and “Battery low”
• CPU controlled shut down: Controlled by user-software, delayed up to 127 sec.
SSD
• Disk capacity: PV-5122: 1.76 MB
• PV-5124: 3.84 MB
• Speed: PV5122: Read 170 KB/sec, write 20 KB/sec
• PV5124: Read 90 KB/sec, write 15 KB/sec
Physical / Environment
• Dimensions: 96x90x18mm
• Temperature range: Operating: -20°C to 70°C
• Storage: -40°C to +85°C
• Humidity: 0 to 90% RH, non-condensing
• Connectors PC/104 Stack-through connectors
• Screw terminals for mains and 12V battery
