4
General Operation
Turning the Monitor On:
The monitor is operational by activating the ignition
key then manually pressing the power switch on the
unit.
MENU CAM MODE POWER
-
+ MENU CAM M
Adjusting the Speaker’s Volume
Press these buttons (- or +) to adjust the speaker’s
volume.
Selecting the Camera View
Press to select the desired camera view.
Note: When the camera is automatically selected (Example:
the vehicle is put into reverse) the camera image will
automatically override the selected camera image.
-
+ MENU CAM MODE POWER
Configuring Monitor’s Camera Display
Press the MODE to select the desired camera display
configuration.
Note: When the camera is automatically selected (Example:
the vehicle is put into reverse) the camera image will
automatically override the selected camera display.
+ MENU CAM MODE POWER
Camera
Display
Configurations
FRONT
REAR
FRONT REAR
LEFT RIGHT
FRONT REAR
LEFT RIGHT
LEFT RIGHT
