1a 1b 1c, Hook up guide hook up guide, Speaker connections

background image

subwoofer

front

speakers

center

AUDIO

OUTPUT

right

left

right

left

FR

FL

C

SR

SL

SPEAKERS

(8

)

CENTER

LINE OUT

AUDIO

OUT

AUDIO

IN

VIDEO

OUT

WOOFER
LINE OUT

TV

AUX

S- VIDEO

OUT

Pr/Cr

Pb/Cb

T

COMPONENT

VIDEO OUT

COAXIAL

OPTICAL

DIGITAL

OUT

AM

FM

(75‰)

AM/FM

ANTENA

75

AUDIO

OUT

L

R

AVIN

75

L

R

AUDIO

OUT

AV IN

Rear of TV

S-VIDEO

IN

2

a

b

c

.047"

(12m

m)

Connecting Speaker Cable

PU

SH

IN

PUSH

DOWN

S-VIDEO

IN

1a

1b

1c

RELEASE

L

R

surround

speakers

SPEAKER CONNECTIONS

a. Connect the Front Right (+,-) speaker wires to

the FR (Red +,-) speaker terminals on the Receiver.

Connect the Front Left (+,-) speaker wires to the

FL (White +,-) speaker terminals.

Connect the Center speaker wires to the C (Green

+,-) speaker terminals.

b. Connect the Surround Right (rear speaker) wires to

the SR (Gray +,- ) speaker terminals.

Connect the Surround Left (rear speaker) wires to

the SL (Blue +,- ) speaker terminals.

c. Connect the Subwoofer speaker AUDIO INPUT

jack to the WOOFER LINE OUT jack on the receiv-
er. Use the supplied black cable with RCA connec-
tors on each end.

Use this simple and quick way to watch your favorite
DVD movie and enjoy your Home Cinema experience!

Flip the page to start DVD playback and arrange the surround speakers.

T

o connect your MRD 250 Home
Cinema Surround Receiver:

H

ELPFUL

H

INTS

Your TV capability determines which
type of video connection you can make
with the DVD Receiver.

to view DVD playback on your

TV. The RF Modulator converts the video from
the Receiver so it can play through the TV’s
Antenna connector.
See your electronics retailer or contact Philips for
details on RF Modulator availability.
If you use an RF modulator, set the TV to channel
3 or 4. Set the RF modulator’s 3/4 switch to the
same channel.

you can connect the receiver using

one of these for a higher quality connection. See
your instruction manual for details.

Hook Up

Guide

Hook Up

Guide

ANT IN

TO TV

AUDIO IN
R

L

VIDEO

IN

CH3 CH4

Back of RF Modulator

(example only)

Antenna or Cable TV Signal

Audio/Video cables from DVD Receiver

RF coaxial cable to TV

OPTIONAL TV Audio Connection

In order to listen to normal TV broadcast channels
through the Home Cinema Surround Receiver (if your
TV has AUDIO OUT jacks) you must make an audio
connection.

IMPORTANT! The Receiver will use all surround
sound speakers only if the TV broadcast is in a surround
sound format (Dolby Digital, DTS, Dolby Pro Logic). If
the broadcast is in stereo only, some of the surround
speakers will not be active.

Connect the red and white pair of audio cables from

the TV AUDIO IN (Left & Right) jacks on the
Receiver to the AUDIO OUT (Left & Right) jacks on
the TV.

NOTE: When listening to TV programs, the Receiver

must be set to the AUX mode for the sound to be heard.

If your TV has S-Video or
Component (PB PR Y) jacks

Pr/Cr

Pb/Cb

Y

If your TV only has a single Antenna In
jack, you will need an accessory RF
Modulator

75

Y

ANTENNA IN

VIDEO CONNECTION

Connect the yellow VIDEO OUT jack on the

Receiver to the matching VIDEO IN jack on the TV.

2

x5

x1

1

S-VIDEO

IN

Y
