-3-
Shave
Blend
S tar t
CORDLESS Frozen
Concoction Maker ®
PARTS LIST
1 Ice Reservoir Lid – Covers the Ice Reservoir.
2 Ice Reservoir – Holds the ice for making
frozen drinks.
3 Shaving Paddle – Moves ice across the
Shaving Blade.
4 Ice Hopper – Guides ice towards Shaving Blade.
5 Ice Shaving Blade with Defl ector – Shaves ice.
6 Shaving Blade Assembly Nut –
Holds Shaving Blade in place.
7 Ice Chute – Directs shaved ice from Ice Hopper
into Blending Jar.
8 Blending Base – Holds Blending Jar
securely in place.
9 Control Panel – Contains all necessary
controls to operate your unit.
10 Charger – Charges the Battery.
11 Jar Lid – Seals the blending jar.
12 Blending Jar – Maximum capacity
of 36 oz (1 Liter).
13 Blending Blade Sealing Ring – Seals
the Blending Jar and Blending Base.
14 Blending Blade – Mixes shaved ice
with ingredients.
15 Jar Base – Designed with wide base
for stability.
16 Ice Melt Reservoir – Captures
melted ice excess.
17 18 Volt Battery Pack – Supplies
power to the unit.
2
3
9
8
1
7
5 6
4
10
