ThinkCore W315/325/W345 Hardware User’s Manual
Hardware Introduction
2-3
ThinkCore W345
Top View
Wireless GSM/GPRS
antenna connector
Relay Output
Reset Button
1. Internal SD Slot for
Storage Expansion
2. Internal SIM Card Slot
(remove cover to access)
Reset
RELAY
12-48V
LAN
NO
COM
NC
USB
12 to 48 VDC
Ethernet
10/100BaseTX
USB 2.0 Host
Front View
Wireless
GSM/GPRS
antenna
Serial
console port
Ethernet
(10/100BaseTx)
12 to 48 VDC
Serial Port 1 to 4
(RS-232/422/485)
Relay Output
USB 2.0 Host x 2
1. Internal SD Slot for
Storage Expansion
2. Internal SIM Card Slot
(remove cover to access)
W345
RX
TX
P3 P 4
P3 P 4
GPR S
P1 P2
P1 P2
Wireless Embedded Computer
Ready
Bottom View
Serial Port x 4
(RS-232/422/485)
