2.2 Connecting the Cable
• Plug the 15-pin male connector on the video cable into the output connector
on the rear of your computer system. The video output connector on your
computer may be either in a location similar to Figure 2-2
or on an expansion
board. Secure the cable to the computer using the thumbscrews on the 15-
pin connector.
• Attach the power cord to the monitor and plug it into an AC outlet.
• The monitor is now ready for use.
Expansion boards
COM1
COM2
LPT1
VIDEO
Figure 2-2 Monitor Connections
Figure 2-1 Connecting the Base
