Hanging the TV and Vertical Adjustment Bars
on the Wall Plate
Monster strongly recommends that a minimum of two people
perform the following steps.
DO NOT release the TV until you are certain it is properly mounted
and secured to the wall plate.
Connect the TV’s power cord and any AV cable to the TV before hanging it.
With the help of a friend, lift the TV and plug its power cord into a nearby
AC outlet. If routing AV cable in wall, route the cable through the wall
plate’s Pass-Thru slots into the prepared opening in your wall.
Locate the two sets of QuickLift ™ QuickLift QuickLift hooks on the back of the Vertical
Adjustment Bars, now attached to your TV.
Hang either the upper or lower pair of QuickLift hooks on the wall plate’s QuickLift QuickLift
top and bottom horizontal channels. (See diagram on opposite page.)
The higher display position requires an additional 3" of audio/video cable
and power cord length.
Secure the display with the L-Shaped Locking Bars. Slide them horizontally
through the slot below either bottom hook.
The locking bar should always be used to reduce the risk of seismic
damage. A padlock can be added for additional theft deterrence.
1)
2)
3)
4)
5)
6)
