UTP VDS REMOTE LONG RANGE UNIT
3
Setting the dipswitches
All 3 sets of dipswitches must have the same settings.
Set dipswitches 1 – 3 of each set according to the cable length, screen resolution
and refresh rates. See the table below.
Note! Dipswitch number 4 is not used.
Cable Length
Screen Resolution and Refresh Rates
M
ft
640x480
75 Hz
800x600
75 Hz
1024x768
75 Hz
1280x1024
75 Hz
50
165
ON
OFF
1 2 3
ON
OFF
1 2 3
ON
OFF
1 2 3
ON
OFF
1 2 3
100
330
ON
OFF
1 2 3
ON
OFF
1 2 3
ON
OFF
1 2 3
ON
OFF
1 2 3
150
490
ON
OFF
1 2 3
ON
OFF
1 2 3
ON
OFF
1 2 3
ON
OFF
1 2 3
200
650
ON
OFF
1 2 3
ON
OFF
1 2 3
ON
OFF
1 2 3
ON
OFF
1 2 3
250
820
ON
OFF
1 2 3
ON
OFF
1 2 3
ON
OFF
1 2 3
ON
OFF
1 2 3
