– 4 –
Figure 1: AstroFinder Model 60 Altazimuth Refracting Telescope
1. Eyepiece 13. Diagonal mirror
2. Viewfinder 14. Objective lens cell
3. Viewfinder collimation screws 15. Focuser drawtube
4. Optical tube assembly 16. Altitude rod slow motion fine adjustment control
5. Vertical lock knobs 17. Altitude rod coarse adjustment lock knob control
6. Horizontal lock knob 18. Altazimuth mount
7. Tripod legs 19. Adjustable sliding center leg extension
8. Leg brace supports 20. Sliding leg extension thumbscrew-lock
9. Accessory tray 21. Dew shield/lens shade
10. Tripod-to-mount base attachment point 22. Front lens cap
11. Tripod attachment bolts 23. Focusing knob
12. Accessory tray-to-leg brace wing nut hardware 24. Viewfinder bracket
3
2
5
4
14
22
21
18
10 6
17
23 13
8
12
9
11
7
15
16
19
20
BY MEADE
