Millermatic, The power of blue, Auto-set

Processes
MIG (GMAW)
Flux-Cored (FCAW)
Input Power
208/230 V, 1-Phase, 60 Hz
Industrial Applications
Metal Fabrication
Maintenance and Repair
Farm/Home
Light Industrial
Quick
Specs
Millermatic
®
212
MIG Arc Welding Power Source,
Wire Feeder and Gun Package
Issued Jan. 2013 • Index No. DC/12.46
The Power of Blue
®
.
Rated Output
160 A at 24.5 VDC, 60% Duty Cycle
Max. Open-Circuit Voltage
34.5 V
Amperage Range
30 – 210 A
Wire Feed Speed
50 – 700 IPM (1.3 – 17.8 m/min.)
Weight
178 lb. (81 kg)
Welder is warranted for 3 years, parts and labor.
Original main power rectified parts are warranted for 5 years.
Gun warranted for 90 days, parts and labor.
EZ-Access
™
consumable compartment and
parameter chart. Set weld parameters right the
first time with convenient flip-down compartment
that provides fast access to parameter chart and
consumables.
See page 3 for more information.
Reduce maintenance and
operating costs with our
Fan-On-Demand
™
cooling
system only operates when
needed, reducing power
consumption and contaminants
drawn into the machine.
Line voltage compensation keeps
power constant even if power
input varies by ±10 percent.
Compatible with Spoolmate
™
200
spool gun! The
Spoolmate 200
with wire feed speed
control on the gun saves
time for the operator by
eliminating the need to go
back to the machine to change the
spool gun wire feed speed.
Infinite voltage control replaces “tap”
settings which means that you now can
“dial in” precise weld voltage and wire feed
speed when using the Manual Mode.
Auto-Set
™
is a breakthrough control that
automatically sets your welder to the
proper parameters. Auto-Set makes set
up very simple and gives you precise
settings instantly. See page 2 for details.
Comes Complete With:
15-ft. (4.6 m), 250-amp M-25 MIG gun
for .030/.035-in. wire
10-ft. (3 m) work cable with clamp
7-ft. (2.1 m) power cord and plug
Argon mix regulator/flow gauge and hose
Factory-installed running gear with
EZ-Change
™
Low Cylinder Rack
.030/.035-in. reversible
drive rolls
Extra contact tips
Set-up and operation
interactive CD
Material thickness
gauge (#229 895)
‰
Manual mode allows you to manually
set weld parameters for broader
applications.
Compatible with Bobcat
™
welder/generators.
No more replacing mechanical
output contactors. Our built-in
solid-state contactor circuit makes
wire electrically “cold” until trigger
is pulled, and gives you life-long
welding output and performance.
Auto-Set
™
