MITSUBISHI LANCER 2008-2010
99-7011 DASH DISASSEMBLY
4 Unclip the radio switch panel includ-
ing the hazard switch assembly.
Unplug hazard switch assembly and
remove panel. (Figure C)
5 Remove (4) Phillips screws secur-
ing the radio chassis. Unplug and
remove chassis.
7 Unclip assembly, unplug ribbon
cable from assembly and remove
assembly from the factory radio
panel. Retain screws and hazard
switch assembly for re-use during
kit preparation.
6 Remove (3) Phillips screws securing
the hazard switch assembly to the
factory radio switch panel. Unclip
and remove the switch. (Figure D)
8 Unclip and remove the a/c vents
from the factory radio switch panel.
(Retain a/c vents for re-use during
kit preparation)
9 Remove and retain (7) factory clips
from rear of radio housing for
re-use during kit preparation.
Continue to kit preparation.
PASSENGER
AIRBAG OFF PASSENGER
PASSENGER
AIRBAG OFF
PASSENGER
D
C
