Mace DVR0804RW User Manual
Page 9
9
Parameter
16 Channel
Processor
AMD ELANSC520/133 embedded microprocessor
Operation system
Real-time operation system RTOS
Video input
Channel
BNC 1.0V
P- P
75
Video output
Channel
BNC 1.0V
P- P
75
video signal
Audio input
Channel 200-3000mv10K (RCA)
Audio output
Channel
2000mv 1K (RCA)
Video display
1 4 ,16 window display
Video standard
NTSC 525 line, 60f/s
PAL 625 line, 50f/s
System resource
16 chs real-time recording, one channel playback and network operation simultaneous
Image resolution
Real-time monitor 704 576, playback 352 288, VGA output 720 576
Motion detection
Area setting:
detection areas on the screen; detection sense setting: 3 levels detection sense for
each area
Video compression
CBR (fixed frame rate);
VBR (variable frame rate)
Audio compression
Audio ADPCM 28.8Mbyte/hour
Video 40-460Mbyte/hour
Image compression
rate
352 288 CIF format 704 576 4CIF format
Video
recording
speed
MPEG mode: PAL 1frame/10second-25f/s for each channel adjustable; NTSC 1frame/10second-30f/s
for each channel adjustable
Image quality
6 levels selectable
Hard disk
Inside equipped 4 IDE ports, able to install 8 HDDs inside, expand with external HDD case for another
12 HDDs
Alarm input
16 channel voltage alarm input
5
15V D. C. Needed for the alarm input
Alarm output
6 channels output,
output in open/close contact
Alarm relay
24VDC 1A,220VAC 0.15A relay ouput
connection
Network connection
RJ45 10M/100M Ethernet connection
Pan-tilt control
Alarm input and output port,
Backup
Power
110VAC/220VAC
Power consumption
75W
Working temperature
10
55
Working humidity
10
90
Barometric pressure
86kpa 106kpa
