95-7861 DASH DISASSEMBLY
HONDA PILOT 2006-2008
(Without Factory Navigation)
A
B
2
Disconnect the negative battery-
terminal to prevent an accidental
short circuit. 1
Remove (2) screws from the top
of the instrument panel trim.
Unclip and remove the instrument
panel trim. (Figure A) 2
Unclip and remove the left center trim
panel. (Figure B) 3
Unclip the radio trim panel.
Unplug and remove the panel.
(Figure C) 4
Remove the (4) screws securing
the radio. Unplug and remove the
radio. (Figure D) 5
Continue to kit assembly.
C D
