– 4 –
1. Eyepiece
2. Equatorial mount
3. Right Ascension (R.A.) flexible cable
control
4. Declination (Dec.) flexible cable control
5. Counterweights
6. Counterweight shaft
7. Counterweight lock
8. Safety washer/thumbscrew
9. Viewfinder Dustcover
10. Polar axis
11. Latitude lock knob
12. Optical tube assembly
13. Optical tube saddle plate
14. Optical tube mounting thumbscrews
15. Equatorial mount base
16. Viewfinder bracket mounting bolts
17. Focuser drawtube and eyepiece holder
18. Eyepiece holder thumbscrew
19. Focuser
20. Viewfinder bracket
21. Focus knobs
22. R.A. lock
23. Dec. lock
24. 5 x 24 viewfinder
25. Viewfinder focuser
26. Viewfinder adjustment thumbscrews
27. R.A. setting circle
28. Dec. setting circle
29. Latitude dial
30. Azimuth lock
31. Declination axis
32. Tripod leg brace
33. Tripod leg brace support
34. Tripod legs
35. Tripod-to-mount wingnuts
36. Accessory tray
37. Eyepiece holder slots
38. Mounting bolt hole
39. Telescope front dust cover
40. Collimating Screws
41. Counterweight shaft attachment location
Key to Figs. 1a - 1g
