Moffat Blue Seal GT46E - Manual

Technical data sheet for
VEE RAY TWIN PAN GAS FRYER 450mm
GT46E
Twin pan fryer flexibility – full single pan
performance
Patented infra-red burner system
High performance fast recovery
2 digital display temperature controls with
3 product timers each
Easy clean stainless steel open pan with 10 year
limited warranty
13L oil capacity per pan
Large capacity cool zones
32mm (1
1 /
4
”) drain valves
Rear rollers
Stainless steel exterior
Easy service
Fully modular
Overall Construction
• Stainless steel pan with 10 year limited warranty
• Bull nose welded 1.5mm 304 stainless steel
• Splashback 1.2mm 304 stainless steel
• Side panels 1.2mm 304 stainless steel
• Double skin door with 0.9mm 304 stainless exterior
• 32mm (1
1 /
4
”) drain valve per pan
• 63mm dia. heavy-duty 1.2mm 304 stainless steel adjustable legs at
front and two rollers at rear
• 2 baskets and stainless steel lid supplied standard
Controls
• Digital display electronic thermostats
• Thermostat range 88-193°C
• 3 programmable product timers with countdown display and
alarms per pan
• Straight or temperature compensating cook time control
• Heating and basket drop displays
• Programmable melt cycles
• Over-temperature safety cut-outs
• Flame failure protection on each pilot
• Piezo ignition to standing pilot burners
Cleaning and Servicing
• Open stainless steel pans for easy clean
• Easy clean basket support bar
• 32mm (1
1 /
4
”) drain valves for effective draining
• Easy clean stainless steel exterior
• Access to all parts from front of unit
GT46E
