- 9 -
LED Indicators
The front panel of EDS-208 contains several LED indicators. The function of
each LED is described in the table below.
LED Color State Description
On
Power is being supplied to the
power input
P AMBER
Off
Power is not being supplied to
the power input
On TP port’s 10 Mbps link is active
Blinking
Data is being transmitted at 10
Mbps 10
(TP)
GREEN
Off
TP Port’s 10 Mbps link is
inactive
On TP port’s 100 Mbps link is active
Blinking
Data is being transmitted at 100
Mbps
100
(TP)
GREEN
Off 100BaseTX Port’s link is inactive
On FX port’s 100 Mbps link is active
Blinking
Data is being transmitted at 100
Mbps
100M
(FX)
GREEN
Off 100BaseFX Port’s link is inactive
Auto MDI/MDI-X Connection
The Auto MDI/MDI-X function allows users to connect EDS-208’s
10/100BaseTX ports to any kind of Ethernet device, regardless of how the
Ethernet cable is wired. This means that you can use either a straight-through
cable or cross-over cable to connect EDS-208 to Ethernet devices.
Dual Speed Functionality and
Switching
EDS208’s 10/100 Mbps switched RJ45 port auto negotiates with the connected
device for the fastest data transmission rate supported by both devices. All
models of EDS-208 are plug-and-play devices, so that software configuration
is not required at installation, or during maintenance. The half/full duplex
mode for the switched RJ45 ports is user dependent and changes (by
auto-negotiation) to full or half duplex, depending on which transmission speed
is supported by the attached device.
