K00175 WATER FILTER BIN BRACKET

Installation Instructions



1. Water filter bin bracket can be used to mount all Tri-liminator water filter assemblies on either side or back of any Manitowoc ice

bin.

2. Remove foam tape from area where bracket is to be mounted, hang bracket, and install foam tape, provided with kit, over top of

bracket. Locate ice machine, per installation instructions.

3. Using screws and flatwashers provided, fasten Tri-liminator assembly to bracket.
4. Using two grommets, insert into holes in bracket.


Manitowoc Ice, Inc.

2110 South 26

th

Street, P.O. Box 1720, Manitowoc, WI 54221-1720 USA

Telephone 920-682-0161, Fax - Sales: 920-683-7589, Service/Parts: 920-683-7585, Other: 920-683-7879 8005473
Web Site - www.manitowocice.com

Rev. 06/11/03

Tri-liminator Assembly

Ice Bin

#10-24 x 1/2 lg. screw
and flatwasher

Foam Tape

Water Filter Bin Bracket

Grommet
