Model 627 – MTD OEM-190-627 User Manual
Page 17
17
Model 627
REF.
NO.
PART NO.
DESCRIPTION
1
611-0132
Rod Assembly
2
710-3131
Hex Cap Screw, 1/2-13 x 1.0
3
710-0151
Hex Cap Screw, 3/8-24 x 2.0
4
710-0964A
Hex Cap Screw, 5/8-18 x 1.31
5
710-0514
Hex Cap Screw, 3/8-16 x 1.0
6
711-0332
Clevis Pin, .5 x .78
7
712-0386A
Slotted Hex Nut, 5/8-18
8
712-3022
Hex Lock Nut, 1/2-13
9
714-0474
Cotter Pin, .125 x .75
10
714-0470
Cotter Pin, 1/8 x 1.25
11
714-0507
Cotter Pin
12
716-0102
Snap Ring
13
732-0262
Extension Spring
14
736-0366
Flat Washer, .64 x 1.12 x .125
15
736-0272
Flat Washer, .51 x 1.0 x .060
16
710-0331
Hex Cap Screw, 3/8-24 x 2.25
17
756-0300
Flat Washer, .406 x .875 x .059
18
738-0234
Shoulder Screw, .5 x .29, 3/8-16
19
741-0170
Flange Bearing w/ Flats
20
736-0169
Lock Washer, 3/8
21
738-0347
Shoulder Spacer, .625 x .169
22
783-0382
Link, 4.88
23
783-0878
Link, 13.25
24
783-1263
Link, 17.30
25
784-5727
Idler Pivot Arm
26
784-5728
Idler Support Bracket
27
756-3080
Double Pulley, 7.0 x 3.5
28
710-3180
Hex Cap Screw, 5/16-18 x 1.75
29
716-3020
Internal Snap Ring
30
750-3164
Spacer, .635 x 2.0
31
736-0290
Flat Washer, 5/8 x 1.0 x .063
32
712-3004A
Flange Lock Nut, 5/16-18
33
712-3010
Hex Nut, 5/16-18
34
710-3151
Hex Cap Screw, 5/8-18 x 4.25
35
736-0329
Lock Washer, 1/4
36
714-0145
Click Pin, .092 x 1.64
37
712-3006
Hex Nut, 1/4-20
38
747-3250
Belt Guard Rod
39
711-0242
Spacer
40
712-0241
Hex Nut, 3/8-24
41
712-0116
Nylon Jam Lock Nut, 3/8-24
42
712-3017
Hex Nut, 3/8-16
43
747-0871
Belt Keeper Rod
44
754-0449
Upper V-belt
45
756-0627
Idler Pulley, 3.5” Diameter
46
741-0524
Sealed Ball Bearing, .625 x 1.574 x .470
47
603-0302
Chute Tilt Bracket Assembly
48
710-0262
Carraige Bolt, 5/16-18 x 1.5
49
710-0451
Carraige Bolt, 5/16-18 x .75
50
710-0896
Hex Index Washer Screw, 1/4-14 x .625
51
710-3015
Hex Cap Screw, 1/4-20 x .75
52
712-0429
Nylon Hex Lock Nut, 5/16-18
53
710-0376
Hex Cap Screw, 5/16-18 x 1.0
54
712-3027
Hex Flange Lock Nut, 1/4-20
55
720-0232
Knob
56
731-0851A
Chute Flange Keeper
57
731-1300A
Lower Chute
58
731-1313C
Chute Tilt Cable Guide
59
731-1320
Upper Chute
60
736-0231
Flat Washer, .344 x 1.125 x .125
61
736-0242
Bell Washer, .34 x .872
62
736-0451
Saddle Washer, .32 x .93
63
746-0929
Chute Cable w/ Clip, 54.5”
64
746-0928
Chute Cable, 54.5”
65
784-5594
Cable Bracket
66
784-5604
Chute Tilt Handle
67
683-0298
Lift Bracket Assembly
68
703-2728A
Snow Thrower Lift Bracket
69
710-3008
Hex Cap Screw, 5/16-18 x .75
70
710-1268
Hex Index Washer Screw #10-16 x .375
71
710-3143
Pan Phillips Screw, #10-24 x .75
72
712-0127
Flat Weld Nut, #10-24
73
756-0218
Flat Idler Pulley, 3.25
74
715-0114
Heavy Duty Spirol Pin, 1/4 x 1.5
75
720-0274
Handle Grip
76
732-0306
Compression Spring, .406 x .531 x 1.75
77
736-0119
Lock Washer, 5/16
78
736-0140
Flat Washer, .385 x .62 x .063
79
736-0400
Flat Washer, .194 x .62 x .063
80
746-3060A
Lift Cable, 42” w/ Trigger Control
81
747-1203
Lift Index Rod
82
750-1028A
Lift Handle Tube
83
710-0805
Hex Cap Screw, 5/16-18 x 1.5
84
715-0138
Rolled Pin, 1/8 x .63
85
715-0129
Spirol Pin, .125 x .82
86
720-0201A
Crank Knob
87
726-0100
Push Cap, 3/8 ID
88
735-0234
Rubber Grommet , .44 x .94 x .5
89
741-0475
Plastic Bushing
90
747-0697
Eye Bolt
91
747-0931
Chute Crank Rod, .38 x 28
92
747-0932
Rod, .375 x 11.375
93
750-1054
Support Chute Tube
94
784-5149
Joint Block Assembly
95
684-0061
Chute Crank Assembly
96
703-2735A
Chute Crank Bracket
97
705-5226
Chute Reinforcer
98
710-0276
Splined Carriage Screw, 5/16-18 x 1.0
99
710-0167
Carriage Screw, 1/4-20 x .5
100
731-1379A
Adapter Chute
101
784-5647
Chute Crank Bracket
102
710-3144
Hex Cap Screw, 3/8-16 x 2.0
103
725-0157
Cable Tie
104
683-0133
Pulley Mounting Bracket Assembly
105
783-0358A
Idler Bracket
106
783-0362A
Mounting Strap Hanger Bracket
107
783-0372
RH Side Plate
108
783-0373
LH Side Plate
109
710-3168
Carriage Bolt, 3/8-16 x 1.0
110
710-0650
Self-tapping Screw, 5/16-18 x .875
111
783-1274
Heat Shield
112
736-0101
Flat Washer, .406 x 1.0 x .030
113
747-0533
Clutch Adjustment Control Rod
114
732-0626
Extension Spring, .75 x 5.06
115
714-0101
Internal Cotter Pin
116
736-3019
Flat Washer, .531 x 1.062 x .134
117
783-0359
Idler Engagement Bracket
118
711-0198
Ferrule, 3/8-24 x .375
