6
HD 135 / HD 155
74
x
x
Power cable (Fused plug –> Item 7000)
3G x 1.50 x 5500
840 241 3108
75
x
x
Pressure stop switch cable assembly
100 761 9711
76
x
x
Tallow-drop screw, galvanized
4 x 20
618 609 4300
77
x
x
Bracket
134 161 5794
78
x
x
Switch cover
134 161 5786
79
x
On/off switch HD 135
811 262 1980
x
On/off switch HD 155
811 261 6846
80
x
x
Housing, lower
134 161 5867
81
x
x
Switch enclosure, upper
134 161 5808
82
x
x
Gasket, lower switch enclosure
2 x 96 x 151
763 141 0027
83
x
x
Cap screw, galvanized
M4 x 60
84
612 001 9595
84
x
x
Washer, galvanized
A 4.3
125
630 001 6330
85
x
x
Hexagon nut, galvanized
M4
934
620 000 2197
86
x
x
Housing centre part
134 161 5859
87
x
x
Axle
12 x 356
134 561 5926
88
x
x
Wheel
727 061 5915
89
x
x
Spring collar
12 x 25
640 360 9119
90
x
x
Wheel cover
134 161 5891
91
x
x
Tallow-drop screw, galvanized
6 x 30
618 915 3765
92
x
x
Filter screen
770 315 5175
93
x
Spring seat
134 163 4225
x
Hexagon socket head cap screw
M5 x 30
912
612 114 2803
94
x
Spring
705 118 7312
x
Handle mount
134 163 4268
95
x
Pressure piece
134 141 8638
x
Nut
M5
934
620 000 2200
96
x
High-pressure hose
NW6 x 5000 160 bar
134 663 4061
97
x
Handle
134 163 0874
98
x
Screw
617 203 2905
99
x
Handle tube
134 264 3970
100
x
Crank
134 163 4608
101
x
Bearing block
134 163 4594
102
x
Axle
134 163 4586
103
x
Hose reel side panel
134 163 4551
104
x
Drive dog
134 163 4578
105
x
Screw, Plastite
M5 x 20
7985
618 915 3781
106
x
Hose reel drum
134 163 4560
107
x
Banjo bolt
134 563 4629
108
x
Connector
134 363 4656
109
x
Screw, galvanized
M5 x 12
84
612 000 0061
110
x
Connecting hose
NW6 x 143 230 bar
134 663 4673
111
x
Screw, Plastite
M4 x 20
7985
618 609 4300
112
x
Hexagon nut, galvanized
M5
934
620 000 2200
113
x
Union nut
M22 x 1.5
134 963 9030
114
x
Plug nipple
G 1/4 male
134 563 4696
115
x
O-ring
10 x 2.2
763 210 6690
116
x
High-pressure hose
M22 x 1.5 ÜM - G 1/4 male
134 663 4703
125
x
Hose clamp
134 164 5472
126
x
Pipe elbow 90
°
3/4"
787 663 9020
127
x
O-ring
15 x 5
763 263 9044
128
x
x
Spring washer
3 x 3.7
672 008 3831
Component part assemblies:
200
x
x
Pressure stop switch
100 763 6705
201
x
x
Unloader O-ring set
100 763 6691
202
x
Unloader valve assembly HD 135
100 763 6683
x
Unloader valve assembly HD 155
100 763 6675
203
x
x
Pump head
100 763 6667
204
x
x
Adaptor O-ring set
100 763 6640
205
x
x
Valve set
100 763 6659
206
x
x
Piston casing gasket kit
100 718 8605
207
x
x
Piston set (with springs)
100 718 8613
208
x
Wobble plate repair kit HD 135
100 763 6624
x
Wobble plate repair kit HD 155
100 763 6632
209
x
Electric motor assembly HD 135
100 763 6608
x
Electric motor assembly HD 155
100 763 6616
210
x
Motor switch assembly HD 135
100 763 6586
x
Motor switch assembly HD 155
100 763 6594
211
x
Hose reel assembly
100 763 4176
H.P. accessories:
300
x
x
H.P spray gun
134 963 4054
301
x
x
Multi-power lance
134 963 3767
302
x
x
Turbo nozzle
134 963 4135
303
x
x
Injector attachment
100 761 1826
Misc.:
7000
x
x
Fused plug, type BS 1363 (GB only)
821 514 8077
Item
HD
135
HD
155
Description
Dimension
DIN
Stock-no.
