6A1 ENGINE (E - W) - Piston and Connecting Rod
11A-14-1
14. PISTON AND CONNECTING ROD
REMOVAL AND INSTALLATION
Apply engine oil to all
moving parts before
installation.
6AE0095
Removal steps
" G A 1. Nut
A
A
" "
F
A 2. Connecting rod cap
"
E
A 3. Connecting rod bearing
"
D
A 4. Piston and connecting rod
"
E
A 5. Connecting rod bearing
" C A 6. Piston ring No.1
" C A 7. Piston ring No.2
"
B
A 8. Oil ring
A
B
" "
A
A 9. Piston pin
10. Piston
11. Connecting rod
12. Bolt
PWEE9622
E
