Timing belt, 6a1 engine (e - w), Removal and installation Page 19
Page 19
6A1 ENGINE (E - W) -
Timing Belt
11A-4-1
4. TIMING BELT
REMOVAL AND INSTALLATION
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
11 Nm
21 Nm
9 Nm
48 Nm
24 Nm
49 Nm
35 Nm
88 Nm
17
18
11 Nm
11 Nm
11 Nm
11 Nm
Removal steps
1. Timing belt front cover, upper right
2. Timing belt front cover, upper left
3. Timing belt front cover, lower
4. Engine support bracket
5. Angle sensor
A
A
" "
C
A 6. Timing belt
7. Tensioner pulley
8. Tensioner arm
9. Tensioner spacer
"
B
A 10. Auto tensioner
11. Crankshaft sprocket
12. Sensing plate
13. Crankshaft spacer
A
B
" "
A
A 14. Camshaft sprocket bolt
15. Camshaft sprocket
16. Idler pulley
17. Timing belt rear cover, center
18. Connector bracket
PWEE9622
E
Feb. 1997
Mitsubishi Motors Corporation
