REPLACEMENT PARTS
17
RINSE BOOSTER ASSEMBLY
AND RINSE SYSTEM
Fig.5 Part
Item No. No. Part Description Qty.
1 40010061 Rinse Booster Assy (Includes Item 26) ................................................... 1
2 60090028 Hose Clamp ............................................................................................. 6
3 60060066 Tee 12MM x 3/8 BSP Branch ................................................................. 1
4 1672 Rinse Solenoid Assy (Includes Items 17-25) .......................................... 1
5 60060073 Hose ......................................................................................................... 15ft
6 88461 Bolt Hex SST M6 x 12 ........................................................................... 1
7 40030048 Crox Tailpiece MCO 1/2". ...................................................................... 1
8 40020061 Bracket Rinse tank Mounting .................................................................. 1
9 6083 Elbow Crox-Female 15MM Brass .......................................................... 1
10 60090060 Ball Polypropylene PB030 7/16" ............................................................ 1
11 8566 Washer Spring M6 .................................................................................. 1
12 60060067 Socket 3/8 x 1/8 Nylon Reducing ........................................................... 1
13 6001 Nut Crox 15MM Brass ............................................................................ 1
14 60080052 Bolt Pan Slot M3 x 6 ............................................................................... 1
15 60030088 Thermostat ............................................................................................... 1
16 40030072 Wash Spindle ........................................................................................... 2
17 6153 Tailpiece 1/2 x 1/2 ................................................................................... 1
18 3324 Coil, Solenoid 240V 10W LED .............................................................. 1
19 3321 Body, Solenoid EVSI10 .......................................................................... 1
20 60060003 Nipple 1/2" x 2" Brass ............................................................................. 1
21 6075 Musen Ring Saddle Clamp Brass 20MM ................................................ 1
22 6950 Strainer Line 1/2" .................................................................................... 1
23 6047 Nipple Hex 1/2" ....................................................................................... 1
24 60080009 Nut SST Hex M10 ................................................................................... 2
25 60080024 MS Hex SST 304 M10 x 60 .................................................................... 1
26 3005 Element 5KW 208-240V (Includes Cap & Gasket) ................................ 1
