Philips Magnavox 13MT143S User Manual

75 ω

ANEL

AYOUT

ANEL

NDEX

Panel

Sequence

and

Panel Index

COVER

SAFETY

INFO

MODEL

REGISTRATION
INFORMATION

PANEL

Subject

Panel No.

Alternate Channel . . . . . . . . . . . . . . . . . .26
Antenna Basic Connection . . . . . . . . . . . .1
Front Audio/Video Input Jacks . . . . . . . . .3
Automatically Program TV . . . . . . . . . . . .9
Basic Cable Connection . . . . . . . . . . . . . .1
Basic Remote Operation . . . . . . . . . . . . . .4
Basic Television Operation . . . . . . . . . . . .4
Cable Box Connection . . . . . . . . . . . . .1-2
Cable TV Control (Tuner Mode) . . . . . . .8
Care and Cleaning . . . . . . . . . . . . . . . . . .28
Channel Edit . . . . . . . . . . . . . . . . . . . . . .10
Closed Caption Control . . . . . . . . . . . . .21
Factory Service Locations . . . . . . . . .30-31
Format Control . . . . . . . . . . . . . . . . . . . .13
Glossary . . . . . . . . . . . . . . . . . . . . . . . . . .29
Language Control . . . . . . . . . . . . . . . . . . .7
Limited Warranty . . . . . . . . . . . . . . . . . .32

Subject

Panel No.

Picture Menu Controls . . . . . . . . . . . . . .11
Remote Batteries . . . . . . . . . . . . . . . . . . . .4
Remote Control Button Descriptions .5-6
Sleeptimer . . . . . . . . . . . . . . . . . . . . . . . .22
SmartLock™ Controls

Access Code . . . . . . . . . . . . . . . . . . . . .15
Block Channels . . . . . . . . . . . . . . . . . . .16
Blocking/Clearing All Channels . . . . . . .17
Movie Ratings . . . . . . . . . . . . . . . . . . . .18
Other Blocking Options . . . . . . . . . . . .20
TV Ratings . . . . . . . . . . . . . . . . . . . . . . .19
Understanding SmartLock™ . . . . . . . .14

SmartPicture™ Control . . . . . . . . . . . . .23
SmartSound™ Control . . . . . . . . . . . . . .24
SmartSurf . . . . . . . . . . . . . . . . . . . . . . . .25
Troubleshooting . . . . . . . . . . . . . . . . . . .27

Side 1

Side 2

SmartPicture

, SmartSound

, and SmartLock

are regis-

tered trademarks of Philips Consumer Electronics North
America. Copyright © 2003 Magnavox. All rights reserved.

Thank you for choosing Magnavox.

Need help fast?

SER

ANUAL

Color Television

Read your User Manual first for quick tips that make using

your Magnavox product more enjoyable. If you have read

your instructions and still need assistance you may access our

online help at

www.magnavox.com

call 1-800-705-2000

while with your product.

IB8470E001

Once your MAGNAVOX purchase is registered, you’re eligible to receive all the privileges of owning a
MAGNAVOX product. So complete and return the Warranty Registration Card enclosed with your pur-
chase at once. And take advantage of these important benefits.

Return your Warranty Registration card today to

ensure you receive all the benefits you’re entitled to.

Warranty
Verification

Registering your product
within 10 days confirms your
right to maximum protection
under the terms and condi-
tions of your MAGNAVOX
warranty.

Owner
Confirmation

Your completed Warranty
Registration Card serves as
verification of ownership in
the event of product theft or
loss.

Model
Registration

Returning your Warranty
Registration Card right away
guarantees you’ll receive all
the information and special
offers which you qualify for
as the owner of your model.

Visit our World Wide Web Site at http://www.magnavox.com

For Customer Use

Enter below the Serial No. which is locat-
ed on the rear of the cabinet. Retain this
information for future reference.
Model No. ________________________
Serial No. ________________________

Know these

safety

symbols

This “bolt of lightning” indicates uninsu-
lated material within your unit may

cause an electrical shock. For the safety of
everyone in your household, please do not
remove product covering.

The “exclamation point” calls attention
to features for which you should read

the enclosed literature closely to prevent
operating and maintenance problems.
WARNING: TO PREVENT FIRE OR
SHOCK HAZARD, DO NOT EXPOSE THIS
EQUIPMENT TO RAIN OR MOISTURE.
CAUTION: To prevent electric shock,
match wide blade of plug to wide slot, fully
insert.
ATTENTION: Pour éviter les choc élec-
triques, introduire la lame la plus large de la
fiche dans la borne correspondante de la
prise et pousser jusqu’au fond.

Congratulations on your
purchase, and welcome to
the “family!”

Dear MAGNAVOX product owner:
Thank you for your confidence in MAGNAVOX.
You’ve selected one of the best-built, best-
backed products available today.We’ll do every-
thing in our power to keep you happy with
your purchase for many years to come.
As a member of the MAGNAVOX “family,”
you’re entitled to protection by one of the
most comprehensive warranties and outstand-
ing service networks in the industry.
What’s more, your purchase guarantees you’ll
receive all the information and special offers for
which you qualify, plus easy access to acces-
sories from our convenient home shopping
network.
Most importantly, you can count on our
uncompromising commitment to your total
satisfaction.
All of this is our way of saying welcome-and
thanks for investing in a MAGNAVOX product.

P.S. Remember, to get the most from
your MAGNAVOX product, you must
return your Warranty Registration Card
within 10 days. So please mail it to us
right now!

I S

T R

A T I O N

D
E

Hurry!

IMPORTANT SAFETY INSTRUCTIONS

Read before operating equipment

Read these instructions.

Keep these instructions.

Heed all warnings.

Follow all instructions.

Do not use this apparatus near water.

Clean only with a dry cloth.

Do not block any of the ventilation openings. Install in accordance
with the manufacturers instructions.

Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that produce heat.

Do not defeat the safety purpose of the polarized or grounding-type
plug. A polarized plug has two blades with one wider than the other.
A grounding type plug has two blades and third grounding prong.
The wide blade or third prong are provided for your safety. When
the provided plug does not fit into your outlet, consult an electrician
for replacement of the obsolete outlet.

10.

Protect the power cord from being walked on or pinched particularly
at plugs, convenience receptacles, and the point where they exit from
the apparatus.

11.

Only use attachments/accessories specified by the manufacturer.

12.

Use only with a cart, stand, tripod, bracket, or table
specified by the manufacturer, or sold with the appara-
tus. When a cart is used, use caution when moving the

cart/apparatus combination to avoid injury from tip-over.

13.

Unplug this apparatus during lightning storms or when unused for
long periods of time.

14.

Refer all servicing to qualified service personnel. Servicing is required
when the apparatus has been damaged in any way, such as power-
supply cord or plug is damaged, liquid has been spilled or objects
have fallen into apparatus, the apparatus has been exposed to rain
or moisture, does not operate normally, or has been dropped.

15.

This product may contain lead and mercury. Disposal of these materi-
als may be regulated due to environmental considerations. For dispos-
al or recycling information, please contact your local authorities or
the Electronic Industries Alliance: www.eiae.org

16.

Damage Requiring Service - The appliance should be serv-
iced by qualified service personnel when:
A.

The power supply cord or the plug has been damaged; or

Objects have fallen, or liquid has been spilled into the appli-
ance; or

The appliance has been exposed to rain; or

The appliance does not appear to operate normally or
exhibits a marked change in performance; or

The appliance has been dropped, or the enclosure damaged.

17.

Tilt/Stability - All televisions must comply with recommended
international global safety standards for tilt and stability properties of
its cabinet design.
• Do not compromise these design standards by applying excessive
pull force to the front, or top, of the cabinet which could ultimately
overturn the product.
• Also, do not endanger yourself, or children, by placing electronic
equipment/toys on the top of the cabinet. Such items could unsus-
pectingly fall from the top of the set and cause product damage
and/or personal injury.

18.

Wall or Ceiling Mounting - The appliance should be mount-
ed to a wall or ceiling only as recommended by the manufacturer.

19.

Power Lines - An outdoor antenna should be located away from
power lines.

20.

Outdoor Antenna Grounding - If an outside antenna is
connected to the receiver, be sure the antenna system is grounded so
as to provide some protection against voltage surges and built up
static charges.
Section 810 of the National Electric Code, ANSI/NFPA No. 70-1984,
provides information with respect to proper grounding of the mast
and supporting structure, grounding of the lead-in wire to an anten-
na discharge unit, size of grounding connectors, location of antenna-
discharge unit, connection to grounding electrodes, and requirements
for the grounding electrode. See Figure below.

21. Object and Liquid Entry - Care should be taken so that

objects do not fall and liquids are not spilled into the enclosure
through openings.comply with recommended international global safety
standards for tilt and stability properties of its cabinet design.

22.

Battery Usage CAUTION - To prevent battery leakage that
may result in bodily injury, property damage, or damage to the unit:
• Install all batteries correctly, with + and - aligned as marked on
the unit.
• Do not mix batteries (old and new or carbon and alkaline, etc.).
• Remove batteries when the unit is not used for a long time.

ANTENNA LEAD IN WIRE

ANTENNA DISCHARGE UNIT
(NEC SECTION 810-20)

GROUNDING CONDUCTORS
(NEC SECTION 810-21)

GROUND CLAMPS

POWER SERVICE GROUNDING ELECTRODE SYSTEM
(NEC ART 250, PART H)

GROUND CLAMP

ELECTRIC SERVICE EQUIPMENT

Note to the CATV system installer: This
reminder is provided to call the CATV system
installer's attention to Article 820-40 of the NEC
that provides guidelines for proper grounding and, in
particular, specifies that the cable ground shall be
connected to the grounding system of the building,
as close to the point of cable entry as practical.

Example of Antenna Grounding
as per NEC - National Electric Code

f Cable TV signal into your home is a
single cable (75 ohm) the connection

to the TV is easy.

Connect the Cable TV cable
directly to the 75

Ω jack on the

TV.

Basic Cable TV Connection

Basic Antenna Connection

75Ω

Cable TV Signal

RF Coaxial
Cable 75Ω

Rear of TV

combination antenna receives normal
broadcast channels (VHF 2-13 and

UHF 14-69). Your connection is easy
since there is only one 75

Ω (ohm)

antenna plug on the back of your TV -
and that’s where the antenna goes.

If your antenna has a round
cable (75 ohm) on the end, then
you're ready to connect it to the
TV. Go to step 2.
If your antenna has flat twin-
lead wire (300 ohm), you first
need to attach the antenna wires
to the screws on a 300 to 75
ohm adapter (not supplied with
TV).

Push the round end of the
adapter or antenna cable onto
the 75

Ω jack on the rear of the

TV. If the round end of the
antenna cable is threaded, screw
it down tight.

75Ω

Combination

VHF/UHF Antenna

(Outdoor or Indoor)

Twin Lead

Wire

Round Cable 75Ω

Rear of TV

Cable Box Connections

TV/VCR

CABLE

USB

DVD-D OUT

AUDIO IN

SPDIF

VIDEO

IN OUT

S-VIDEO

R L

AUDIO OUT

PASSCARD

Y Pb Pr

OPTICAL

SPDIF

75Ω

Jack Panel Back of Cable Box

Cable Signal IN
from the Cable

Company

Round 75

Ω

Coaxial Cable

Jack Panel Back of TV

f you cable signal uses a cable box or
decoder, follow the easy steps below to

complete the connection.

Cable Box (w/RF In/Outputs):
This connection will be mono.

Connect the Cable Company
supplied cable to the signal
IN(put) plug on the back of the
Cable Box.

Using a separate round coaxial
cable, connect one end to the
OUT(put)

(TO TV) plug on

the back of the Cable Box.

Connect the other end of the
round coaxial cable to the 75

Ω

input on the back of the television.
Screw it down finger tight.

NOTE: If applicable, set the OUTPUT
CHANNEL SWITCH on the back of the
cable box to CH 3 or 4. Tune the TV to
the same channel and change channels
at the cable box. In some cases, the
cable box will automatically tune to
either channel 3 or 4, change channels
until the picture appears.

ANTENNA

OUT

ANTENNA

VIDEO

AUDIO

OUT

ó VOLUME +

CHANNEL

POWER

AUDIO

VIDEO

ó VOLUME +

VOLUME +

CHANNEL

POWER

AUDIO

VIDEO

Front AV (Audio/Video) Input Connections

udio and Video Front Inputs are avail-
able for a quick connection of a VCR,

to playback video from a camera, or
attach a gaming device. Use the AV but-
ton on the remote control to tune these
inputs.

Connect the video (yellow)
cable from the Video output on
the Camera (or accessory device)
to the Video (yellow) Input locat-
ed on the FRONT of the TV.

For Mono Devices: Connect
one end of the audio cable from
the Audio Out jack on the device
to the Audio In (white) jack on
the FRONT of the television.

For Stereo Devices: Connect
one end of the audio cables from
the Audio Out jacks on the
device to the Audio In (red and
white) jacks on the FRONT of
the television.

Turn the TV and the accessory
device ON.

Press the CH+ or CH- but-
ton on the remote control to
tune the TV to the front input
jacks. “AV” will appear on the TV
screen.

Press the PLAY

button on

the accessory device to view
playback, or to access the acces-
sory device (camera, gaming unit,
etc.).

VCR, Camcorder,

DVD

Player, etc. with

Audio and

Video Out jacks

Front Jack panel of TV

White

Audio cable

Yellow

Video

cable

ó VOLUME +

VOLUME +

CHANNEL

POWER

ANTENNA

OUT

ANTENNA

VIDEO

AUDIO

OUT

VCR,

Camcorder,

DVD

Player, etc.

with

Audio and

Video Out jacks

Front Jack panel of TV

Red and White

Audio cables

Yellow

Video

cable

Mono Devices

Stereo Devices:

POWER

VOL

STATUS

EXIT

SLEEP

MUTE

SMART


SOUND

SURF

A/CH

MAGNAVOX

Description of Remote Control Buttons

NUMBER Buttons
Press the Number buttons to select TV
channels or to enter values in the menu.
For single-digit channels, press the
Number button for the channel you
want. The TV will pause briefly before
going to the chosen channel.

A/CH Button
(Alternate Channel)
Press to switch between the last channel
and the present channel.
Details are on panel 26.

STATUS/EXIT Button
Press to see the current channel number.
Press to remove a menu.

CC Button
Press to activate Closed Captioning.
Details are on panel 21.

SLEEP Button
Press to set the TV to turn itself off with-
in a certain time. Details are on panel 22.

SmartSurf
If your TV model has SmartSurf, press this
button to move through the channels you
have set. Details are on panel 25.

Continued on Next Panel

Basic TV and Remote Control Illustrations

Press POWER to turn on the
TV.

Press VOLUME + to increase
the sound level. Press VOLUME
– to lower the sound level.
Press both buttons at the
same time to display the TV’s
on-screen menu. Once in the
menu, use these buttons to make
menu adjustments or selections.

Press CHANNEL ;8 or 9 to
select TV channels.

Television

Point the remote control toward
the remote sensor on the front of
the TV when operating the TV.

Remote Control

To load the supplied batteries into
the remote:

Remove the battery compart-
ment lid on the back of the
remote.

Place the batteries (two AA)
in the remote. Be sure the (+)
and (-) ends of the batteries line up
correctly (as marked inside the
remote).

Reattach the battery lid.

Battery Installation

ó VOLUME +

POWER

CHANNEL

POWER

CHANNEL

AUDIO

VIDEO

AUDIO

VIDEO

Non-Stereo

models (white

AUDIO IN jack)

Stereo models (red and

white AUDIO IN jacks)

Remote
Sensors

(point

remote

here)

Connect an acces-
sory device to the
AUDIO/VIDEO IN

jacks.

A/CH

POW

STA

TUS

EXIT

SLE

MUT

MEN

SUR

SMA

PICT

URE

UND

CH+

CH–

VOL

–

Connect

headphones

(not sup-

plied) to the

; jack.

Remote sensor on

remote control

Battery Installation

The current channel number will
appear briefly when you first turn on
the TV or when you change channels.

Press STATUS/EXIT to see the cur-
rent channel number.

Helpful Hints

How to Use the Language Control

or our Spanish speaking TV owners
an on-screen LANGUAGE option is

present. With the LANGUAGE control
you can set the TV’s on-screen menu to
be shown in either English or Spanish.

Press the MENU button on
the remote to show the on-
screen menu.

Press the CURSOR UP

or DOWN

buttons to

scroll through the on-screen
menu until the word
INSTALL is highlighted.

Press the CURSOR RIGHT

button to display the
INSTALL menu features.

Press CURSOR UP

DOWN

buttons to scroll

the Install features until the
word LANGUAGE is high-
lighted.

Press the CURSOR RIGHT

button repeatedly to
select ENGLISH or
ESPAÑOL (Spanish).

When finished, press the
STATUS /EXIT button to
remove the menu from the
TV’s screen.

The Language control only makes
the TV’s on-screen MENU items
appear in English or Spanish text.

It does not change the other on-
screen text features such as Closed
Caption (CC) TV shows.

ELPFUL

INT

Main
Sound
Features
Install

Brightness
Color
Sharpness
Tint
More...

Main
Sound
Features
Install

Language
Tuner Mode
Auto Program
Channel Edit

Install
Language

Tuner Mode

Auto Program
Channel Edit

English

Instalar
Idioma
Sintonia
Auto Programa
Editar Canal

POWER

VOL

STATUS

EXIT

SLEEP

MUTE

SMART


SOUND

SURF

A/CH

MAGNAVOX

Description of Remote Control Buttons

(Cont’d)

POWER

VOL

STATUS

EXIT

SLEEP

MUTE

SMART


SOUND

SURF

A/CH

MAGNAVOX

POWER button
Press to turn the TV on or off.

CH(annel) +/– Buttons
Press to scan memorized channels.

VOL(ume) +/– Buttons
Press to increase or decrease the
sound.

MENU Button
Press to see the menu. Press
repeatedly to return to previous
menus or remove the menus.

Arrow

2 3 5

Buttons

Press to select or adjust items in
the menu.

MUTE Button
Press to eliminate or restore the TV
sound. MUTE will appear on the TV
when the sound is muted.

SMART SOUND Button
Press to choose a sound setting.
Details are on

panel 24

SMART PICTURE Button
Press to choose a picture setting.
Details are on

panel 23

OW TO

UTOMATICALLY

ROGRAM

When CABLE is selected, channels
1-125 are available.
When ANTENNA is selected,
channels 2-69 are available.
When AUTO is selected, the TV
will automatically set itself to the
correct mode based on the type of
signal it detects when the AUTO
PROGRAM feature is activated.

ELPFUL

INT

Auto Program
Channel

Main
Sound
Features
Install

Brightness
Color
Sharpness
Tint
More...

Main
Sound
Features
Install

Language
Tuner Mode
Auto Program
Channel Edit

Install
Language

Tuner Mode

Auto Program
Channel Edit

Auto Program
Channel

POWER

VOL

STATUS

EXIT

SLEEP

MUTE

SMART


SOUND

SURF

A/CH

MAGNAVOX

our TV can automatically set itself
for local area (or Cable TV) chan-

nels. This makes it easy for you to
select only the TV stations in your
area when the CHANNEL (+) or (–)
buttons are pressed.

Note: Make sure the antenna or
cable signal connection has been
completed before AUTO PROGRAM
is activated.

Press the MENU button
on the remote to show the
on-screen menu.

Press the CURSOR UP

or DOWN

buttons to

scroll through the on-screen
menu until the word
INSTALL is highlighted

Press the CURSOR
RIGHT

button to dis-

play the INSTALL menu
features.

Press CURSOR UP

DOWN

buttons to

scroll the Install features until
the words AUTO PRO-
GRAM are highlighted.

Press the CURSOR
RIGHT

button to start

the Auto Program scanning
of channels. Auto
Programming will store all
available channels in the TV’s
memory then tune to the
lowest available channel
when done.

When finished, press the
STATUS/EXIT button to
remove the menu from the
TV’s screen.

he TUNER MODE control allows you

to change the TV’s signal input to

either ANTENNA, CABLE, or AUTO
mode. It’s important for the TV to know
what type of signal that is connected.
(From a Cable TV signal or a normal
Antenna signal.) In the AUTO mode,
when the AUTO PROGRAM feature is
activated, the TV will automatically
choose the correct mode.

Press the MENU button on
the remote to show the on-
screen menu.

Press the CURSOR UP

DOWN

buttons to scroll

through the on-screen menu until
the word INSTALL is highlight-
ed.

Press the CURSOR RIGHT

button to display the
INSTALL menu features.

Press CURSOR UP

DOWN

buttons to scroll

the Install features until the
words TUNER MODE is high-
lighted.

Press the CURSOR RIGHT

button to select either
ANTENNA, CABLE, or
AUTO mode.

When finished, press the
STATUS /EXIT button to
remove the on-screen menu
from the TV’s screen.

Main
Sound
Features
Install

Brightness
Color
Sharpness
Tint
More...

Main
Sound
Features
Install

Language
Tuner Mode
Auto Program
Channel Edit

Install
Language

Tuner Mode
Auto Program

Channel Edit

English

Antenna

Install

Language
Tuner Mode

Auto Program
Channel Edit

English

Cable

Install
Language

Tuner Mode
Auto Program

Channel Edit

English

Auto

POWER

VOL

STATUS

EXIT

SLEEP

MUTE

SMART


SOUND

SURF

A/CH

MAGNAVOX

OW TO

SE THE

UNER

ODE

ONTROL

OW TO

SE THE

ICTURE

DJUSTMENT

ONTROLS

o adjust your TV picture controls, select a

channel and use the Picture Menu Controls

listed below:

Brightness: Press the CURSOR
RIGHT

3 or LEFT 2 buttons

until the darkest parts of the picture
are as bright as you prefer.

Color: Press the CURSOR
RIGHT

3 or LEFT 2 buttons

to add or eliminate color.

Picture: Press the CURSOR
RIGHT

3 or LEFT 2 buttons

until lightest parts of the picture
show good detail.

Sharpness: Press the CURSOR
RIGHT

3 or LEFT 2 buttons to

improve detail in the picture.

Tint: Press the CURSOR RIGHT

3 or LEFT 2 buttons to obtain
natural skin tones.

Color Temp: Press the CURSOR
RIGHT

3 or LEFT 2 buttons

to select NORMAL, COOL, or
WARM picture preferences. (NOR-
MAL will keep the whites, white;
COOL will make the whites, bluish;
and WARM will make the whites,
reddish.)

Contrast +: Press the CURSOR
RIGHT

3 or LEFT 2 buttons to

toggle the control On or OFF. The
Contrast + control helps to “sharp-
en” the picture quality. The black
portions of the picture become rich-
er in darkness and the whites
become brighter.

Brightness
Color
Sharpness

Tint

Color Temp.

Brightness

Color


Sharpness

Color Temp.

Normal

Warm

Cool

Contrast +

Off

Tint

OW TO

DD OR

ELETE

HANNELS

hannel Edit makes it easy for you to ADD

or DELETE channels from the list of chan-

nels stored in the TV’s memory.

Press the MENU button on the

remote to show the on-screen menu.

Press the CURSOR UP

DOWN

buttons to scroll

through the on-screen menu until the

word INSTALL is highlighted.

Press the CURSOR RIGHT

button to display the INSTALL menu

features.

Press the CURSOR UP

DOWN

buttons to scroll the

Install features until the words

CHANNEL EDIT are highlighted.

Press the CURSOR RIGHT

button to display the CHANNEL

EDIT options

With the CHANNEL EDIT

options displayed, and CHANNEL

NO. highlighted; you can use the cur-

sor buttons to scroll through all avail-

able channels that you wish to add

(Skipped OFF), or delete (Skipped

ON) from the TV’s memory. You can

also use the NUMBERED buttons

to go directly to a specific num-

bered channel that you wish to

add or skip. Or, you can also use the

CH + or CH - to quickly scan the

channels that have not been skipped.

Using the CURSOR DOWN

button, scroll the menu to highlight

the word SKIPPED.

Now use the CURSOR RIGHT

button to toggle between ON or

OFF.

If ON is selected the channel is

skipped when scrolling channels

with the CH + or – buttons. If

OFF is selected the channel is not

skipped when scrolling channels

with the CH + or – buttons.

When finished, press the STA-

TUS /EXIT button to remove the

menu from the TV’s screen.

VOL

Channel Edit
Channel No.
Skipped

Main
Sound
Features
Install

Brightness
Color
Sharpness
Tint
More...

Main
Sound
Features
Install

Language
Tuner Mode
Auto Program
Channel Edit

Install
Language

Tuner Mode

Auto Program
Channel Edit

Channel No.
Skipped

Channel Edit
Channel No.
Skipped

Off

POWER

VOL

STATUS

EXIT

SLEEP

MUTE

SMART


SOUND

SURF

A/CH

MAGNAVOX

An “X” appearing in front of any channel
will indicate that channel has skip on. When
the CH + or CH - buttons are used, those
channels will be skipped.
In order to get to the external input chan-
nel AV, you must use the CURSOR Right

or CURSOR LEFT

2 buttons.

ELPFUL

INT

OW TO

SE THE

ORMAT

ONTROL

XPAND

4:3)

any times while watching movies from
a DVD player the image is shown in

“letter box” format. This is the format that is
shown in movie theaters. When shown on a
TV screen, the image will have areas of
black on top and bottom of the screen.

Press the MENU button on the
remote to display the on-screen
menu.

Press the CURSOR DOWN

button until the word FEA-
TURES is highlighted.

Press the CURSOR RIGHT

button to display the FEATURES
menu options (SmartLock or
Format).

Press the CURSOR DOWN

button until the word FORMAT
is highlighted.

Press the CURSOR RIGHT

or CURSOR LEFT

buttons

to select one of the two options 4:3
or Expand 4:3.
4:3 - Standard format for the TV.
Expand 4:3 - Enlarges the picture
to fill out the entire screen area,
eliminating the “letter box” effect.

When finished, press the STA-
TUS/EXIT button to remove the
menu from the TV’s screen.

Note: The Expand 4:3 format can also
be activated using the CURSOR UP

or DOWN

buttons when the

onscreen menu is not being displayed.
Pressing these buttons will toggle the
standard 4:3 format and the Expand 4:3
format.

Main
Sound
Features
Install

Brightness
Color
Sharpness
Tint
More...

Main
Sound
Features
Install

SmartLock
Format

Features
SmartLock
Format 4:3

Features
SmartLock
Format Expand

4:3

Expand 4:3

VOL

POWER

VOL

STATUS

EXIT

SLEEP

MUTE

SMART


SOUND

SURF

A/CH

MAGNAVOX

Some models refer to SmartLock as

AutoLock in the on-screen menu.

These features are the same.

OW TO

SE THE

OUND

ONTROLS

(20MS233S O

NLY

)

Sound

Treble Boost On

Bass Boost
Balance
AVL
Sound

Treble Boost

Balance

Bass Boost

AVL

On
or Off

Sound

Mono

or Stereo

On
or Off
On
or Off

o adjust your TV sound, select and use the
Sound Menu Controls listed below.

Treble Boost: Press the

buttons to turn the control On or
Off. When On, the control will
enhance the high frequency sounds.

Bass Boost: Press the

buttons to turn the control On or
Off. When On, the control will
enhance the low frequency sounds.

Balance: Press the

or but-

tons to adjust the level of sound com-
ing from the left and right speakers.

AVL: (Auto Volume Leveler) Press
the

or buttons to turn the

control On or Off. When On, AVL
will level out the sound being heard
when sudden changes in volume
occur during commercial breaks or
channel changes.

Sound: Press the

or buttons

to select between Stereo or Mono
settings. Note: If Stereo is not pres-
ent on a selected show and the TV is
placed in the Stereo mode, the
sound coming from the TV will
remain in the Mono mode.

NDERSTANDING THE

MART

OCK

™ C

ONTROLS

he SmartLock™ feature is an integrated cir-

cuit that receives and processes data sent by

broadcasters, or other program providers, that
contain program content advisories. When pro-
grammed by the viewer, a TV with SmartLock™
can respond to the content advisories and block
program content that may be found objection-
able (such as offensive language, violence, sexual
situations, etc.). This is a great feature to censor
the type of viewing children may watch.

SmartLock™ offers various BLOCK-
ING controls from which to choose:

Access Code - An Access Code must be
set to prevent children from unblocking
questionable or censored programming set
by their parents.

Channel Block - After an access code has
been programmed, you can block individual
channels including the A/V inputs.

Clear All - Allows you clear all channels
being blocked from your viewing set with
the Channel Block Control.

Block All - Allows you to block ALL chan-
nels and A/V inputs at one time.

Movie Ratings - Certain blocking options
exist which will block programming based on
ratings patterned by the Motion Pictures
Association of America.

TV Ratings - Just like the Movie Ratings,
programs can be blocked from viewing using
standard TV ratings set by TV broadcasters.

MOVIE RATINGS
G: General Audience - All ages admitted.
Most parents would find this program suit-
able for all ages.
PG: Parental Guidance Suggested - This
programming contains material that parents
may find unsuitable for younger children.
PG-13: Parents Strongly Cautioned - This
programming contains material that parents
may find unsuitable for children under the age
of 13.

MOVIE RATINGS Continued
R: Restricted - This is programming is specifi-
cally designed for adults. Anyone under the
age of 17 should only view this programming
with an accompanying parent or adult guardian.
NC-17: No one under the age of 17 will
be admitted. - This type of programming
should be viewed by adults only.
X: Adults Only - This type of programming
contains one or more of the following: very
graphic violence, very graphic and explicit or
indecent sexual acts, very coarse and intensely
suggestive language.

TV RATINGS
TV-Y -- Designed for a very young audience,
including children ages 2-6.
TV-Y7 -- It may be appropriate for children
age 7 and above who have acquired the devel-
opment skills needed to distinguish between
make-believe and reality.
TV-G -- Suitable for most audiences, this type
of programming contains little or no violence,
no strong language, and little or no sexual dia-
logue or situations.
TV-PG -- This program contains material
that parents may find unsuitable for younger
children. Could contain Moderate violence (V),
some sexual situations (S), infrequent coarse
language (L), or some suggestive dialogue (D).

TV-14 -- This program contains some materi-
al that many parents would find unsuitable for
children under 14 years of age. This type of
programming contains one or more of the fol-
lowing: intense violence (V), intense sexual sit-
uations (S), strong coarse language (L), or
intensely suggestive dialogue (D).

TV-MA -- This program is specifically
designed to be viewed by adults and therefore
may be unsuitable for children under 17. This
type of programming contains one or more of
the following: graphic violence (V), explicit sex-
ual situations (S), or crude indecent language
(L).

If no Video Signal is present, the TV
will shut itself off in about 10 min-
utes. If the TV is tuned to the AV
channel and there is no Video Signal
present, the screen will remain black.

Use Auto Program as described on
panel 9 to set up channels that are
available in your area. Use the CH +/–
buttons to scan available channels.

Helpful Hints

If no Video Signal is present, the TV
will shut itself off in about 10 minutes.
If the TV is tuned to the AV channel
and there is no Video Signal present,
the screen will remain black.

Helpful Hints

13MT143S
13MT1532
13MT1533
20MT133S
20MS233S

NOTE: For model 13MT1533
Audio sound is only available
via the headphone

NOTE:
For model 13MT1533
Audio sound is only
available via the
headphone

NOTE: For model 13MT1533
Audio sound is only available
via the headphone
