Bourdon Tube Socket–Material/Size
A
S
Specify
Tube
Type
C-Tube
C-Tube
Thru 1,000 psi
(6.89 MPa) [68.95 bar]
Thru 1,000 psi
(6.89 MPa) [68.95 bar]
Range Selection Limits
psi (MPa) [bar]
Grade A Phosphor Bronze (Tube)
Brass (Socket)
316 Stainless Steel
(Tube and Socket)
Tube/Socket Material
PT-96107B page 2 of 2
Typical Installation
The photo at right shows the PT167EX installed
in a lead line. For optimum effectiveness, the
PT167EX should be installed ahead of all other
devices or valves; by positioning it immediately
adjacent to the well outlet, the Swichgage instru-
ment monitors the entire lead line, sensing any
blockage whether sludge build-up in the line or
an accidental closed valve. The pressure trans-
mitter threads into a 2 NPT tee on the lead line.
LOW C HIGH
Black White
Red
Internal Wiring
Contact Rating: 1 A, 125 V AC
Ranges
vacuum/psi Specify kPa/MPa bar
0 - 100 psi
0 - 160 psi
0 - 200 psi
0 - 300 psi
0 - 400 psi
0 - 600 psi
0 - 1000 psi 100
160
200
300
400
600
1000 0 - 689 kPa
0 - 1.10 MPa
0 - 1.38 MPa
0 - 2.07 MPa
0 - 2.76 MPa
0 - 4.14 MPa
0 - 6.89 MPa 0 - 6.89
0 - 11.03
0 - 13.78
0 - 20.68
0 - 27.57
0 - 41.36
0 - 68.95
How to Order
To order, specify pressure range, bourdon tube and options. Example: PT167EX-R-200-T1.
PT167EX – ___ – ___
If specifying range in bar, kPa/MPa or kg/cm 2 ,
specify appropriate designator after value.
Example: 20B = 20 bar.
B = Bar
K = kPa/MPa
M = kg/cm
2
Tamperproof Contact Accessory
Knob
Lock
Limit
Switch
Knobs
Order 05000610
