MTD PPN 31A-040-401 - Manual

5
4
3
12
11
21
10
2
3
15
14
12
18
16
20
19
5
19 5
18
19
5
19
5
14
17
15
6
7
8
9
Item Part No. Description
1 753-04427 Switch Asm
2 753-04428 Bushing
3 753-04429 Cable guide
4 753-04430 Screw
5 753-04431 Nut
6 753-04432 Bail
7 753-04433 Upper Handle
8 753-04434 Guide Bar
9 753-04435 Cord Restraint
10 791-182677 Knob
11 753-04052 Washer
12 791-182899 Bolt
13 753-04436 Lower Handle
14 753-04437 Wheel
15 753-04062 Push Cap
16 753-04438 Spacer
17 753-04439 Axel
18 791-182213 Bolt
19 791-182678 Washer
20 753-04440 Wheel Bracket
21 753-04441 Control Rod Bracket
HANDLE PARTS - MODEL ELECTRIC SNOW THROWER
ELECTRIC SNOW THROWER
PPN 31A-040-401
1
13
