Lift the basket from the rest position and
lower into the cooking position in the hot
oil.
Lower the handle by pulling back the
handle release button and lower handle into
its recess.
Assembly/Disassembly
sequence
The fryer has to be disassembled and
assembled following this procedure.
• Open the lid and remove.
• Remove the basket.
• Lift out the tank.
• Pull out the pod control.
Assembly is the reverse of the above
process.
Removal of the pod
1 Lift up the fryer body at the front as
shown and pull out the pod.
2 Replace by locating the pod in the
guides and push fully in.
3 Once the pod is in place route the mains
cable to the side or out of the back,
whichever is convenient.
Replacing the bowl
Ensure bowl contacts are dry before
replacing.
