Marantz MV5100 - Manual (Page 54)

• If your DBS does not respond to the
code at step 7, the Controller will
not change channels at the DBS
during a timer recording. In this
case, you must select the channel to
be recorded at the DBS before a
timer recording begins. Enter the
DBS output channel (03 or 04) at
step 3 on page 40. Leave the DBS
on for the timer recording. Details
are on page eight.
Helpful Hint
54 Setting the Controller to Operate a DBS (cont’d)
SELECT CODE NUMBER
OF YOUR DBS RECEIVER
40
DID DBS RECEIVER
CHANGE TO CHANNEL 205?
A YES
NO
SELECT: 89 CONFIRM:OK
END: MENU
6
Press the PLAY 8 or STOP 9 button to set the two-digit
code for your DBS (see list below), then press the
OK/STATUS button.
7
Wait for a few seconds.
• If the DBS changes to channel 205, go to step 8.
• If the DBS doesn’t change to channel 205, press the PLAY 8 or
STOP 9 button to select NO, then press the OK/STATUS but-
ton. Repeat steps 6-7, using a different code for your brand (if
available).
• If the DBS does not respond to any of the codes, press the
MENU button to remove the menu. DBS RECEIVER CONTROL
IS OFF will appear on the screen briefly.
8
Press the PLAY 8 or STOP 9 button to select YES, then
press the OK/STATUS button. “DBS RECEIVER CONTROL IS
ON” will appear for five seconds. “AS A RESULT AUTO CLOCK
WILL BE TURNED OFF” may appear on the screen also.
DBS CODES
MAGNAVOX DBS .........................................................42, 43
RCA DBS................................................................................40
SONY DBS.............................................................................41
7 Wait for a few seconds.
6-8
VCR TV
VCR/TV
QUICK PROGRAMMING
POWER
STILL/SLOW
SMARTPICTURE
CH VOL
MENU
TIMER
JOG/SHTL
TURBO
TIMER
AUDIO/
MUTE
SKIP
SEARCH
TAPE
MANAGER
OK/STATUS
- .......... .......... +
CBL/DBS
1 – + * 2 ABC 3 DEF
4 GHI 5 JKL 6 MNO
7 PQRS 8 TUV 9 WXYZ
START STOP DATE
VPS/PDC DAILY
SPEED DBS/SAT
PLAY
REW FF
STOP
WEEKLY
/OTR REC
-
+
-
+
ALT 0 CLEAR
SAT/
REV FWD
MV5100 27-84 7/21/00 10:59 AM Page 54
