MITSUBISHI ELECTRIC Diamond Plus 92 - Manual (Page 5)

- 1 -
ENGLISH
CAUTION
The power cord provided with this monitor is de-
signed for safety and must be used with a properly
grounded outlet to avoid possible electrical shock.
Do not remove the monitor cabinet as this can
expose you to very high voltages and other hazards.
Trademark
IBM, PC, PS/2, PS/V, Personal System/2 are registered trade-
marks of International Business Machines Corp.
Apple Macintosh is a registered trademark of Apple Computer, Inc.
Quadra is a trademark of Apple Computer, Inc.
UNIX is a registered trademark in the United States and other
countries, licensed exclusively through X/Open Company Limited.
E NERGY S TAR is a U.S. registered mark.
© 2001 Mitsubishi Electric Australia Pty.Ltd.
1. INTRODUCTION ................................................... 2
1.1 Features ...................................................... 2
1.2 Internal Preset Memory Capability .............. 3
1.3 Power Management Function ..................... 3
1.4 DDC ............................................................ 3
1.5 Location Considerations ............................. 3
1.6 Cleaning Your Monitor ................................ 3
1.7 Unpacking ................................................... 4
1.8 Tilt/Swivel Base ........................................... 4
Screen Position Adjustment ........................ 4
1.9 Quick Operation Chart ................................ 4
2. PART NAME .......................................................... 5
2.1 Control Names ............................................ 5
2.2 Function ...................................................... 5
3. INSTALLATION AND CONNECTION ................... 6
3.1 AC Power Connection ................................. 6
3.2 Signal Cable Connection ............................ 6
3.2.1 Connecting to any IBM VGA Compatible
System ................................................. 6
3.2.2 Connecting to an Apple Macintosh
Computer ............................................. 6
4. OSD(On Screen Display) FUNCTIONS ................ 7
4.1 How to adjust the screen ............................ 7
4.2 Adjustment Items ........................................ 8
5. TROUBLESHOOTING .......................................... 10
6. SPECIFICATIONS ................................................. 12
7. APPENDIX ............................................................ 13
7.1 Optional Macintosh Adapter AD-A205 settings 13
8. WARRANTY .......................................................... 15
CONTENTS
WARNING!
This product is not designed for use in life support
devices and Mitsubishi Electric Australia Pty.Ltd. makes
no representations to the contrary. Life support de-
vices are those devices which are used to measure,
diagnose, or evaluate the tissue, systems or functions
of the human body; or other devices employed to
support or sustain life or good health.
