CANOPY INSTALLATION
INSTALLING CANOPY
A canopy is furnished with each firebox and MUST be installed for safe operation. See Figure 15.
1. Remove the three (3) screws from the top front frame assembly. Also remove the two (2) screws on the side frames.
See Figure 15.
2. Align the canopy with the holes in the top frame.
3. Replace the screws previously removed.
4. Tighten side screws. Make sure the canopy is level and
secure.
The firebox canopy must not be
modifi ed or replaced with a canopy
that may be provided with the unvented
decorative room heater.
W
ARNING
Close fi replace screen panel before
operating a decorative type unvented
room heater.
W
ARNING
Figure 15 - Installing Canopy
