Mustang Survival MD3183 - Manual (Page 11)

Re-arming Your PFD
NOTE: A valid re-arm kit (MA7214) is required for this procedure.
1) Place the Inflatable PFD (Personal Flotation Device) on a smooth, flat
surface and wipe off any water. Access the inflator by reaching under
the cover and pull it toward you, turning the cell and cover inside-
out to fully expose the inflator for re-arming. Hold the CO2 cylinder
through the fabric, using one hand (Fig. 8).
FIGURE 8
2) Insert the metal key between the black locking ring and labeled
yellow cap. Turn the key counter-clockwise (Fig. 9).
Locking Ring Key
FIGURE 9
3) Turn the black locking ring counter-clockwise and lift off the cap
(yellow inflator operating head Fig. 10). Dispose of the used cap.
8 Inflatable PFD Owner’s Manual Inflatable PFD Owner’s Manual 9
