Chapter 2. Connecting 27
A/V Receiver (Stereo System)
Figure 7
Most setups require either a digital audio cable or stereo audio
cables. In some circumstances, you may need to connect both
digital audio and stereo audio. A digital audio cable is provided
with the TV. Stereo audio cables are not included.
• To connect an analog A/V receiver:
Connect a set of stereo audio cables from AUDIO
OUTPUT on the TV back panel to the TV AUDIO
INPUT on the back of the A/V receiver. The red cable
connects to the R (right) channel and the white cable
connects to the L (left) channel.
• To connect a digital A/V receiver with Dolby®
Digital surround sound:
Connect one end of the digital audio cable supplied
with the TV to DIGITAL AUDIO on the back of the
TV. Connect the other end to the COAXIAL DIGITAL
INPUT on the back of the A/V receiver.
*/
*/165 $0"9*"-
T
*/
*/165 $0"9*"-
$0.10/&/5 :1C1S JQQJ */165
47*%&0
7*%&0
"6%*0 -&'5 .0/0
"6%*0 3*()5
%57$"#-& 7)'6)'
%*(*5"- "6%*0 065165 $BCMF$"3%™64&8*5)"/5$"3%501
2
:
1C
1S
"6%*0 -&'5 .0/0
"6%*0 3*()5
065165
"6%*0 065165 3&$03%
065165 %7* "OBMPH"VEJP
7*%&0
AUDIO- LEFT/ (MONO)
"6%*0 3*()5
.0/*503-*/,™)%.*
(-JOL ¸
*/165
1$'03)%.*
"/5."*/ "/5"69
$0.10/&/5 :1C1S JQQJ */165
47*%&0
7*%&0
"6%*0 -&'5 .0/0
"6%*0 3*()5
%57$"#-& 7)'6)'
2
:
1C
1S
"6%*0 -&'5 .0/0
"6%*0 3*()5
065165
3&$03%
065165 %7* "OBMPH"VEJP
7*%&0
AUDIO- LEFT/ (MONO)
"6%*0 3*()5
.0/*503-*/,™)%.*
(-JOL ¸ (-JOL (-JOL
*/165
1$'03)%.*
"/5."*/ "/5"69
"73FDFJWFS3FBS1BOFM
57#BDL1BOFM
6TFPOMZJG
DPOOFDUJOHB
%PMCZEJHJUBM
"7SFDFJWFS
Figure 7. Connecting an A/V receiver
On rare occasions, an HDMI signal may be copy-
restricted and cannot be output from the TV as a digital
signal. To hear these copy-protected signals through the
A/V receiver, use connections for analog A/V receivers.
MP3 audio from memory cards cannot be connected
to digital audio. To listen to MP3 playback from the TV
memory card player through your A/V receiver, use the
connections for an analog A/V receiver
Check the A/V receiver’s Owner’s Guide for information
concerning use of the digital input and switching between
digital sound and analog stereo sound from the TV.
Satellite Receiver or Other Device with
S-Video
Figure 8
An S-Video cable and audio cables are required. These are not
included with the TV.
1. Connect an S-Video cable from VIDEO OUT on the
satellite receiver back panel to INPUT-2 S-VIDEO on
the TV back panel.
2. Connect a set of audio cables from AUDIO OUT on
the satellite receiver back panel to INPUT-2 AUDIO
on the TV back panel. The red cable connects to the
R (right) channel and the white cable connects to the
L (left) channel.
Note: Refer to the Satellite Receiver Owner’s Guide
for Dish Antenna connections
